Schneider Electric ZB4FW353 Illuminated Push-Button
The illuminated push-button head is designed for flush mounting, featuring a vibrant orange operator with a plain lens. It supports integral LED lighting for enhanced visibility. Made with chromium-plated metal, it has a mounting diameter of 1.20 inches (30.5 mm). Suitable for demanding industrial environments, it boasts high resistance to pressure washing, shocks, and vibrations, conforming to IP66, IP67, IP69/IP69K ratings, and IK06 protection. It operates reliably within temperatures from -40°F to 158°F and is certified UL, CSA, CE, and EAC compliant, ensuring durability and safety for control panel applications.
Schneider Electric ZB4FW353 Illuminated Push-Button Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Shape of signaling unit: Round head
- Environmental protection: IP66, IP67, IP69/IP69K, IK06
- Material: Chromium plated metal
- Operational temperature: -40°F to 158°F (-40°C to 70°C)
- Shock resistance: 30 gn for 18 ms
- Vibration resistance: 5 gn from 10 to 500 Hz
- Mechanical durability: 10 million cycles
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C
- Net weight: 10.13 lb (4.6 kg)
- Certification: UL, CSA, CE, EAC
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508
- Environmental compliance: Reach, RoHS, China RoHS
- Package weight: 1 lb (0.45 kg) per unit, various bulk packaging options
- Warranty: 18 months
Buy the Schneider Electric Series Harmony XB4 Signaling: ZB4FW353
Order the Schneider Electric illuminated push-button ZB4FW353 online today to ensure your control panels are equipped with high-quality, durable signaling components. Its orange flush operator with integral LED guarantees excellent visibility. Made from chromium-plated metal, it withstands harsh industrial environments with high resistance to pressure washing, shocks, and vibrations. Certified UL, CSA, CE, and EAC, and designed to operate within temperatures from -40°F to 158°F, it offers a reliable, long-lasting solution for your automation and control needs.
Get Schneider Electric ZB4FW353 today—built for industrial durability and reliable visibility in control systems.
