Schneider Electric ZB4FW383 Signal Push Button
The ZB4FW383 is a premium, flush-mounted illuminated push button designed for industrial control panels. Featuring a yellow operator profile with a plain lens, it offers high resistance to high-pressure washdowns up to 7,000,000 Pa at 55°C and durable mechanical operation with 10 million cycles. Certified to IP66, IP67, IP69, and IP69K standards, this round signaling unit is ideal for harsh environments. Its robust construction includes chromium-plated metal bezels, with mounting diameters of 30.5 mm, ensuring reliability and long-lasting performance in demanding industrial applications.
Schneider Electric ZB4FW383 Signal Push Button Specifications:
- Mounting diameter: 30.5 mm
- Shape: Round head with plain lens
- Head type: Built-in-flush
- Operator profile: Yellow flush, unmarked
- Material: Chromium plated metal bezel
- Environmental protection: IP66, IP67, IP69, IP69K, Type 13, 12, 4, 4X UL 50 E
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Mechanical durability: 10 million cycles
- Electrical composition code: M1, M26, M6, M10
- Operating temperature: -40°C to 70°C
- Weight: 0.06 kg
- Certifications: UL Listed, CSA, CE, EAC, CCC
- Protection degree: IP66, IP67, IP69, IP69K
Buy the Schneider Series Harmony XB4 Signaling Unit: ZB4FW383
Enhance your industrial control panels with this high-quality yellow illuminated push button, engineered for durability and enhanced resistance to high-pressure cleaning. It features a robust chromium-plated metal bezel, a built-in flush head for seamless integration, and certified protection up to IP69K, ensuring outstanding performance even in harsh environments. Easy to install with a mounting diameter of 30.5 mm, this round signaling unit is ideal for demanding automation and control applications, offering long-lasting durability and reliable operation with millions of cycles.
Buy Schneider ZB4FW383 now and experience unmatched reliability and performance for demanding industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW383?
You can click on the BUY or RFQ button to purchase ZB4FW383 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW383?
You can download the ZB4FW383 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW383?
Schneider Electric
