Schneider Electric ZB4FW933 Illuminated Pushbutton
The ZB4FW933 is a round, green, built-in-flush illuminated pushbutton head designed for industrial control panels. It features a chromium plated metal bezel, an IP66/IP67/IP69/IP69K protection rating, and withstands high-pressure washing up to 7,000,000 Pa. The device offers mechanical durability of 10 million cycles, operates within -40°C to +70°C, and supports various electrical compositions with integral LEDs. Its compact size includes a mounting diameter of 30.5 mm, overall dimensions of 36.6 mm width and height, and a depth of 31 mm, making it suitable for demanding industrial environments.
Schneider Electric ZB4FW933 Illuminated Pushbutton Specifications:
- Bezel Material: Chromium plated metal
- Head Type: Built-in-flush
- Shape: Round
- Mounting Diameter: 30.5 mm (1.20 in)
- Overall Width: 36.6 mm (1.44 in)
- Overall Height: 36.6 mm (1.44 in)
- Overall Depth: 31 mm (4.22 in)
- Net Weight: 0.06 kg (10.13 lb US)
- Protection Rating: IP66/IP67/IP69/IP69K
- Electrical Compatibility: Various IEC and UL standards
- Mechanical Durability: 10 million cycles
- Operating Temperature: -40°C to +70°C
- Pressure Resistance: 7,000,000 Pa at 55°C
- Vibration Resistance: 5 gn 10-500 Hz
- Shock Resistance: 30 g for 18 ms, 50 g for 11 ms
- Certifications: UL Listed, CSA, CE, EAC
- Environmental Ratings: Type 12, Type 13, Type 4, Type 4X, IP69K
Buy the Schneider Electric ZB4FW933 – Reliable Pushbutton for Industrial Applications
Purchase the Schneider Electric ZB4FW933 green flush mounted illuminated pushbutton online today to ensure reliable operation in industrial environments. This robust pushbutton features a durable chromium plated metal bezel, IP66/IP67/IP69/IP69K protection, and withstands high-pressure cleaning up to 7 million Pa. It offers a sealing design suitable for harsh conditions, mechanical durability for 10 million cycles, and supports various electrical configurations with integrated LEDs. Ideal for control panels needing high protection and operational longevity, this pushbutton guarantees dependable performance.
Order your Schneider Electric Series ZB4FW933 green illuminated pushbutton today and enhance your industrial control systems with dependable quality.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW933?
You can click on the BUY or RFQ button to purchase ZB4FW933 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW933?
You can download the ZB4FW933 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW933?
Schneider Electric
