Schneider Electric ZB4FW953 Industrial Push-Button Head
The ZB4FW953 is an illuminated push-button head designed for industrial control panels, featuring a flush-mounted orange operator with an illuminated ring for enhanced visibility. Made from chromium-plated metal, it offers robust resistance to environmental factors, including high-pressure water jets and mechanical durability of 10 million cycles. The device is compatible with various mounting and signaling configurations, supporting UL, CSA, and CE standards, and boasts IP66/IP67/IP69 protection ratings, making it suitable for harsh environments. Its compact size ensures easy installation in control and automation systems.
Schneider Electric ZB4FW953 Industrial Push-Button Head Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Bezel material: Chromium plated metal
- Operator shape: Round, flush
- Operator color: Orange, unmarked with illuminated ring
- Net weight: 0.13 Ib (0.06 kg)
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C at 0.1 m distance
- Mechanical durability: 10,000,000 cycles
- Ingress protection ratings: IP66, IP67, IP69, IP69K
- Operating/Storage temperature: -40°C to +70°C (-40°F to +158°F)
- Certifications: UL, CSA, CE, RoHS, EAC
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Warranty: 18 months
Buy the Buy Harmony XB4 Pushbutton Part Number ZB4FW953 Online
Enhance your control panel with the high-performance Harmony XB4 illuminated push-button head, featuring an orange flush operator. Designed for durability, it withstands harsh environments with IP69/IP67/IP66 ratings and resists high-pressure water jets and mechanical wear for up to 10 million cycles. Easy to install with a 1.20-inch mounting diameter, it offers integrated LED illumination for visibility. Perfect for automation systems needing robust, reliable control components for safety and operational efficiency.
Buy Harmony XB4 ZB4FW953 now and experience unmatched reliability and durable industrial control switch performance.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW953?
You can click on the BUY or RFQ button to purchase ZB4FW953 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW953?
You can download the ZB4FW953 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW953?
Schneider Electric
