Schneider Electric ZB4FW983 push button switch
The yellow illuminated push button features a round head with a built-in flush profile and an illuminated ring for clear signaling. It is IP66/IP67/IP69/IP69K protected, suitable for harsh environments, with a robust chromium-plated metal bezel and a mounting diameter of 1.20 inches (30.5 mm). Designed for durability, it withstands 10 million mechanical cycles and high-pressure washing at 55°C. Its environment resistance, certifications including UL and CSA, and multiple overvoltage category ratings make it ideal for industrial control panels and automation systems.
Schneider Electric ZB4FW983 push button switch Specifications:
- Shape of signaling unit: Round
- Head type: Built-in-flush
- Operator profile: Yellow flush, unmarked with illuminated ring
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Net weight: 0.13 lb (0.06 kg)
- Mechanical durability: 10,000,000 cycles
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Environmental protection: IP66/IP67/IP69/IP69K, Type 13 UL 50E, Type 12 UL 50E
- Operating temperature: -40 to 158°F (-40 to 70°C)
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn (18 ms) half sine wave
- Certifications: UL Listed, CSA, CCC, EAC
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, EN/IEC 60947-1
- Toxic heavy metal free, Mercury free
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
Buy the Schneider Electric Series Harmony XB4 Yellow Push Button: ZB4FW983
Order the Schneider Electric ZB4FW983 yellow illuminated push button online today to enhance your control panel with a durable, IP-rated, flush-mounted switch. This high-quality device offers long-lasting mechanical durability, high-pressure wash resistance, and compliance with multiple safety standards. Perfect for harsh industrial environments, it features an illuminated ring for clear signaling, IP66/IP67/IP69/IP69K certifications, and multiple overvoltage categories. Ensure reliable operation with a device designed to withstand rigorous use and extreme conditions, all available for quick online purchase.
Buy Schneider Electric ZB4FW983 now and experience unmatched reliability and performance in industrial control solutions.
