Schneider Electric ZB5AVB4 Red LED Signal Light
The ZB5AVB4 is a red LED light block with an integrated body and fixing collar designed for visual signaling in automation and control panels. It features a protected LED source with a rated voltage of 24V AC/DC, a steady signal type, and a long service life of 100,000 hours at 25°C. The device complies with multiple safety standards, including UL, CSA, and IEC certifications. Its compact dimensions and versatile mounting options make it suitable for industrial environments requiring reliable status indication.
Schneider Electric ZB5AVB4 Red LED Signal Light Specifications:
- Light source: Protected LED, Red
- Supply voltage: 24 V AC/DC, 50/60 Hz, limits 21.6-26.4 V AC, 19.2-30 V DC
- Current consumption: 18 mA
- Service life: 100,000 hours at 25°C
- Rated insulation voltage: 600 V (pollution degree 3)
- Impulse withstand voltage: 6 kV
- Dimensions: Width 30mm, Height 42mm, Depth 32mm
- Mounting: Panel cut-out recommended 22.5 mm diameter
- Protection class: II according to IEC 60536
- Environmental temperature: Storage -40°C to 70°C, Operation -25°C to 70°C
- Vibration resistance: 5 gn, Shock resistance: 50 gn for 11 ms
- Certifications: UL, CSA, DNV, BV, RINA, Lloyds register, GL
- Standards: EN/IEC 60947-1, EN/IEC 60947-5-1, IEC 61000-4-4, IEC 55011
Buy the Schneider Series Harmony XB5 Red LED Indicator: ZB5AVB4
Enhance your industrial control system with the Schneider ZB5AVB4 red LED signal light featuring integrated body and collar design. This durable indicator operates at 24V AC/DC, providing a steady, long-lasting signal, ideal for machine status indication and safety awareness. Its compact dimensions ensure easy installation on panels with a recommended 22.5 mm diameter cut-out. Certified for UL, CSA, and IEC standards, it withstands harsh environments with excellent shock and vibration resistance, ensuring reliable operation in demanding industrial applications. Buy online today for seamless integration and dependable performance.
Buy Schneider ZB5AVB4 now and experience unmatched reliability and performance with high-quality visual signaling for industrial control panels.
Frequently Asked Questions
Where can I buy Schneider Electric ZB5AVB4?
You can click on the BUY or RFQ button to purchase ZB5AVB4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB5AVB4?
You can download the ZB5AVB4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB5AVB4?
Schneider Electric
