Schneider Electric ZB5AVG4 Signal Light Block
The ZB5AVG4 is a red plastic light block with an integral LED, designed for easy mounting in control panels. It operates at 110 to 120 V AC, indicating steady status with its red signaling light. Suitable for industrial automation, it features screw clamp terminals for secure wiring, complies with EN 60947-1 standards, and has a service life of 100,000 hours. Its compact dimensions (30 mm width, 42 mm height, 32 mm depth) make it ideal for panel installation, ensuring reliable operation in harsh environments with protection against electromagnetic interference.
Schneider Electric ZB5AVG4 Signal Light Block Specifications:
- Dimensions: Overall width 30 mm, height 42 mm, depth 32 mm
- Light source: Integral LED, color Red
- Operating Voltage: 110-120 V AC 50/60 Hz
- Current Consumption: 14 mA
- Built-in LED: Steady light signaling
- Material: Plastic (body and fixing collar)
- Connection: Screw clamp terminals, <= 2 x 1.5 mm² with cable end EN 60947-1
- Rated insulation voltage: 600 V
- Impulse withstand voltage: 6 kV
- Tightening torque: 0.8 to 1.2 N.m
- Service Life: 100,000 hours
- Standards: UL, IEC 60947-5-1, CSA
- Environmental: -40 to 70°C, Class II shock protection
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Resistance to transients: 2 kV IEC 61000-4-4
- EMC Immunity: 9.14 V/m IEC 61000-4-3
- Electrostatic Discharge: 6 kV contact / 8 kV air IEC 61000-2-6
- Certifications: UL Listed, DNV, CSA, Lloyd's Register
Buy the Schneider Electric Series ZB5 Signaling: ZB5AVG4
Purchase the Schneider Electric ZB5AVG4 signal light block online for dependable industrial signaling. With integral LED, durable plastic construction, and easy screw clamp terminals, it's perfect for control panels. Operating at 110-120 V AC, it provides steady red illumination, ideal for indicating machine status. Its compact size ensures seamless panel mounting, and with a service life of 100,000 hours, it guarantees long-lasting performance. Order today for reliable, high-quality signaling in your automation system and improve operational safety with ease.
Get Schneider Electric ZB5AVG4 today—built for reliable control signaling and industrial safety.
Frequently Asked Questions
Where can I buy Schneider Electric ZB5AVG4?
You can click on the BUY or RFQ button to purchase ZB5AVG4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB5AVG4?
You can download the ZB5AVG4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB5AVG4?
Schneider Electric
