Schneider Electric ZB5FL4 Pushbutton Head
This is a flush-mounted red projecting pushbutton head designed for industrial control applications. It features a round, unmarked operator profile with a spring return mechanism, built for high durability with 10 million mechanical cycles. The head is made of dark grey plastic, with a mounting diameter of 1.20 inches (30.5 mm). It conforms to IP66, IP67, and IP69K standards, providing excellent protection against dust and water. Suitable for dangerous environments, it supports multiple electrical configurations, including UL and IEC standards, and is designed for reliable operation in harsh conditions. Its compact size and robust design make it ideal for automation systems requiring durable, non-illuminated pushbutton controls.
Schneider Electric ZB5FL4 Pushbutton Head Specifications:
- Mounting Diameter: 1.20 in (30.5 mm)
- Overall Width: 1.46 in (37 mm)
- Overall Height: 1.46 in (37 mm)
- Overall Depth: 1.26 in (32 mm)
- Material: Dark grey plastic
- Operator Profile: Red projecting, unmarked
- Mechanical Durability: 10,000,000 cycles
- Ingress Protection: IP66, IP67, IP69K
- Ambient Temperature (Storage & Operation): -40°F to 158°F (-40°C to 70°C)
- Shock Resistance: 30-50 gn, IEC 60068-2-27
- Vibration Resistance: 5 gn, 10-500 Hz, IEC 60068-2-6
- Standards: UL 508, IEC 60947-5-1, CSA, JIS, DNV, Lloyds
- Certifications: UL Listed, RINA, BV, GL
- Protective Treatments: TH
- Environmental Resistance: Water pressure resistance up to 7,000,000 Pa
- Country of Origin: France
- Package Weight: 0.02 kg
- Warranty: 18 months
Buy the Buy Schneider Electric ZB5FL4 Part Number ZB5FL4 Online
Purchase the Schneider Electric ZB5FL4 pushbutton head online today to ensure reliable and durable control for your automation needs. Crafted with high-quality dark grey plastic, it features a round unmarked operator profile with a spring return mechanism, suitable for harsh industrial environments. This non-illuminated, flush-mounted control component is rated IP66, IP67, and IP69K for superior resistance to dust, water, and high-pressure jets. With a mounting diameter of 1.20 inches and a durability of 10 million cycles, it guarantees long-lasting performance and safety in demanding applications.
Get Schneider Electric ZB5FL4 today—built for high durability, reliable control, and long-lasting operation in industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB5FL4?
You can click on the BUY or RFQ button to purchase ZB5FL4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB5FL4?
You can download the ZB5FL4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB5FL4?
Schneider Electric
