Schneider Electric ZBY9W2B630 Emergency Stop Button
This emergency stop button features a red illuminated ring and a yellow label with black ARRESTO EMERGENZA marking, designed for safety applications in industrial environments. Constructed from durable plastic, it operates on 24 V AC/DC power with protected LED illumination, ensuring high visibility during emergency situations. Its IP66/IP67/IP69 rating guarantees resistance against water, dust, and high-pressure washings. Compatible with IEC 60947 standards, it withstands mechanical shocks and vibrations, providing reliable long-term operation. Ideal for safety circuits, machinery, and control panels requiring certified emergency stop solutions.
Schneider Electric ZBY9W2B630 Emergency Stop Button Specifications:
- Shape: Round
- Color of lens: Red
- Light source: Protected LED
- Rated supply voltage: 24 V AC/DC at 50/60 Hz
- Supply voltage limits: 19.2 to 30 V DC, 21.6 to 26.4 VAC
- Current consumption: 18mA
- Service life: 100000 hours at rated voltage and 25°C
- Protection degree: IP66, IP67, IP69, IP69K conforming to IEC 60529, ISO 20653
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Vibration resistance: 5 gn (10-500Hz)
- Overvoltage category: Class II IEC 60536
- Electrical insulation class: Class II
- Environmental limits: -40°C to +70°C for storage and operation
- Standards: UL 508, IEC 60947-5-1, IEC 60947-5-4, CSA C22.2 No 14
- Certifications: UL listed, CSA
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Surge withstand: 1 kV IEC 61000-4-5
- Electromagnetic compatibility: IEC 61000-4-2/3/4, IEC 55011
- Mechanical durability: 100,000 hours
Buy the Buy Harmony Emergency Stop Button Part Number ZBY9W2B630 Online
Purchase the high-quality emergency stop button with illuminated red ring and yellow label online today. Designed for industrial safety, it features IP66/IP67/IP69 ratings, protected LED illumination, and compliance with IEC standards. Built for durability and long-term reliability, this button withstands harsh environments and mechanical shocks. Its robust construction ensures quick response during emergencies, making it an essential safety component for machinery and control panels. Buy now for a trusted safety solution that enhances workplace security and operational efficiency.
Get Harmony ZBY9W2B630 today—designed for safety, durability, and compliance in industrial emergencies.
