Schneider Electric ZBY9W2G101 Illuminated signaling unit
The ZBY9W2G101 is an illuminated, round signaling unit featuring a red fixed LED lens with a yellow unmarked label, designed for industrial safety and emergency control applications. It has an IP66/IP67/IP69K protection degree, suitable for harsh environments. This device operates at 110-120 V AC, with a service life of 100,000 hours. It is compatible with emergency switching off mushroom push-buttons, providing reliable visual signaling with a steady light type. Its robust plastic housing ensures durability against high-pressure wash resistance and electrical shocks, conforming to IEC standards.
Schneider Electric ZBY9W2G101 Illuminated signaling unit Specifications:
- Range of product: Harmony
- Device type: Illuminated unmarked legend ring
- Shape: Round
- Lighting: Protected LED, Red light source
- Supply voltage: 110...120 V AC at 50/60 Hz, supply voltage limits 100...132 VAC
- Electrical insulation class: Class II conforming to IEC 61140
- Protection degree: IP66, IP67, IP69, IP69K conforming to IEC 60529, ISO 20653
- Vibration resistance: 5 gn (10...500 Hz)
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Service life: 100,000 hours at 25°C
- Resistance to high pressure wash: 7,000,000 Pa at 55°C, 0.1m distance
- Surge withstand: 1 kV conforming to IEC 61000-4-5
- Compatibility: XB4, XB5
- Environmental ratings: -40°C to 70°C (storage and operation)
- Certifications: UL listed, CSA
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508
- Protection classes: Type 13, Type 12, Type 4, Type 4X
- Overvoltage category: Class I conforming to IEC 60536
- Mechanical durability: 18 months warranty, packaging weight 31g
Buy the Buy Harmony Illuminated Unmarked Legend Ring Part Number ZBY9W2G101 Online
Purchase the Harmony illuminated signaling unit ZBY9W2G101 online today for reliable visual alerts in demanding industrial environments. This round signaling device features a durable red LED light protected by IP69K protection, ensuring visibility even under high-pressure cleaning. Designed for emergency and safety applications, it operates at 110-120 V AC with a service life of 100,000 hours. Its robust plastic housing withstands harsh conditions, including resistance to shocks, vibrations, and electrical surges, conforming to IEC standards for safety and durability.
Get Harmony ZBY9W2G101 today—built for industrial safety, featuring high-pressure wash resistance and long-lasting LED illumination.
Frequently Asked Questions
Where can I buy Schneider Electric ZBY9W2G101?
You can click on the BUY or RFQ button to purchase ZBY9W2G101 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZBY9W2G101?
You can download the ZBY9W2G101 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZBY9W2G101?
Schneider Electric
