Schneider Electric ZBY9W2G130 Emergency Stop Indicator Ring
The illuminated emergency stop indicator ring is designed for industrial safety applications, featuring a yellow plastic housing with a red illuminated LED. It is compatible with emergency stop mushroom head push-buttons, providing clear visual signals in safety systems. Operating at 110-120 V AC, it offers a steady light signaling with a durable design, rated for high pressure washer resistance and suitable for harsh environments. The device conforms to IEC and UL standards, with a long service life of up to 100,000 hours and robust protection ratings including IP66, IP67, IP69K, and others, ensuring reliable operation in demanding conditions.
Schneider Electric ZBY9W2G130 Emergency Stop Indicator Ring Specifications:
- Shape of signaling unit head: Round
- Material: Plastic
- Light source: Protected LED
- Light source color: Red
- Rated supply voltage: 110...120 V AC at 50/60 Hz
- Supply voltage limits: 100...132 VAC
- Current consumption: 14 mA
- Service life: 100000 hours at rated voltage and 25°C
- Protection ratings: IP66, IP67, IP69K conforming to IEC 60529 and ISO 20653
- Electrical insulation class: Class II according to IEC 61140
- Resistance to high-pressure washer: 7000000 Pa at 55°C, distance 0.1m
- Overvoltage category: Class I according to IEC 60536
- Vibration resistance: 5 gn (10-500 Hz), IEC 60068-2-6
- Shock resistance: 30 gn (18 ms), IEC 60068-2-27
- EMC resistance: 2 kV transient, IEC 61000-4-4; 10 V/m electromagnetic field, IEC 61000-4-3
- Static discharge resistance: 4 kV contact, 8 kV air, IEC 61000-4-2
- Standards: UL 50E, IEC 60947-5-1, IEC 60947-5-4, UL 508
- Certifications: UL listed, CSA
- Operating temperature: -40°C to +70°C
- Dimensions: Height 60mm, Width 9.3mm, label dimensions @ 60mm
Buy the Brand ZBY9W2G130 – Reliable Emergency Stop Indicator for Industrial Applications
Purchase the ZBY9W2G130 emergency stop indicator ring online today and enhance your safety systems with a highly durable, high-pressure washer resistant, and IP69K-rated signaling device. With a long service life of 100,000 hours and conforming to multiple international safety standards such as UL and IEC, this indicator ensures clear visual communication in safety-critical applications. Its compact round design with a bright red LED inside a yellow plastic housing makes it ideal for demanding industrial environments, providing quick recognition and reliable operation whenever needed.
Buy ZBY9W2G130 now and ensure safety with a robust and visually reliable emergency stop signaling device designed for industrial environments.
