Schneider Electric ZBY9W2M101 Illuminated Indicator Light
The illuminated legend ring provides clear, steady visual signals with a red illuminated ring for safe and reliable operation in industrial environments. Compatible with emergency switching off mushroom head push-buttons, it features a robust plastic housing, protected LED light source, and complies with international standards for safety and durability. Suitable for various signaling applications, this unmarked round sign is designed to withstand high-pressure water jets and harsh conditions, making it ideal for control panels and automation systems where visual indication is essential for operational safety and efficiency.
Schneider Electric ZBY9W2M101 Illuminated Indicator Light Specifications:
- Shape of signaling unit head: Round
- Cap/Operator or lens colour: Red
- Light source: Protected LED
- Light source colour: Red
- Rated supply voltage: 230-240 V AC at 50/60 Hz
- Electrical insulation class: Class II conforming to IEC 61140
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Service life: 100,000 hours at rated voltage and 25°C
- IP degree of protection: IP66, IP67, IP69, IP69K conforming to IEC 60529 and ISO 20653
- Overvoltage category: Class | conforming to IEC 60536
- Vibration resistance: 5 gn conforming to IEC 60068-2-6
- Shock resistance: 30 gn and 50 gn conforming to IEC 60068-2-27
- Resistance to fast transients: 2 kV conforming to IEC 61000-4-4
- Resistance to electromagnetic fields: 10 V/m conforming to IEC 61000-4-3
- Operating temperature: -40°C to 70°C
- Surge withstand: 1 kV conforming to IEC 61000-4-5
- Certifications: UL, CSA listed
- Material: Plastic
- Dimensions: Diameter 60mm, label height 60mm, width 9.3mm
- Connection: Wiring diagram interfaces included
- Mounting: For applications up to IP X9 with recommended hole size 9mm
- Environmental Standards: Complies with multiple safety and durability standards including UL 508, EN/IEC 60947-5-1, JIS C8201.
Buy the Togglery Series Signaling Ring: ZBY9W2M101
Enhance your automation and control systems with the Togglery Series illuminated indicator light, designed for durability and visibility. Featuring a red LED illuminated ring, IP66/IP67/IP69 protection, and high-pressure water jet resistance, it withstands harsh environments. Perfect for emergency stop buttons and control panels, this reliable device meets international safety standards, offering a service life of 100,000 hours. Purchase online today to improve operational safety and efficiency with a robust, certified signaling solution.
Order your Togglery Series ZBY9W2M101 illuminated legend ring today and ensure clear, reliable signaling in your industrial applications.
