Schneider Electric ZBY9W3B630 Emergency Stop Legend Ring
The illuminated emergency stop legend ring features a round plastic housing with a protected LED light source, available in white or red. It is designed for safety applications, complying with IEC and UL standards, and offers IP66/IP67/IP69K protection for demanding environments. This device is rated at 24 V AC/DC, with a service life of 100,000 hours, and is suitable for emergency stop buttons. Its high resistance to pressure washers and electromagnetic compatibility makes it ideal for industrial safety systems and control panels, supporting quick and reliable emergency signaling.
Schneider Electric ZBY9W3B630 Emergency Stop Legend Ring Specifications:
- Shape of signaling unit head: Round
- Light source: Protected LED
- Light source colour: White or red
- Rated supply voltage: 24 V AC/DC at 50/60 Hz
- Electrical insulation class: Class II conforming to IEC 61140
- Protection degree: IP66, IP67, IP69, IP69K conforming to IEC 60529, ISO 20653
- Overvoltage category: Class I conforming to IEC 60536
- Material: Plastic
- Service life: 100000 hours at rated voltage and 25°C
- Surge withstand: 1 kV conforming to IEC 61000-4-5
- Compatibility code: XB4, XB5
- Operating temperature: -40°C to +70°C
- Vibration resistance: 5 gn at 10-500 Hz
- Shock resistance: 30 to 50 gn, 18-11 ms durations
- Resistance to fast transients: 2 kV
- Resistance to electromagnetic fields: 10 V/m
- Resistance to electrostatic discharge: 4 kV contact, 8 kV air
- Standards: UL 50E, IEC 60947-5-1, IEC 60947-5-4, IEC 60068-2-6, IEC 60068-2-27
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Certifications: UL listed, CSA
- Environmental compliance: RoHS, Mercury free, Circularity Profile
Buy the Harmony Series Emergency Stop Legend Ring: ZBY9W3B630
Enhance your safety system with the durable, IP66/IP67/IP69K rated emergency stop legend ring featuring a protected LED light source, available in red or white. This high-performance signaling device offers a service life of 100,000 hours, withstands harsh environmental conditions, and complies with major safety standards including UL and IEC certifications. Its robust plastic housing and high resistance to pressure washers make it ideal for industrial safety applications, control panels, and emergency signaling, ensuring quick and reliable operation when needed most.
Buy Harmony Series emergency stop illuminated legend ring ZBY9W3B630 now and enhance safety with reliable, durable signaling for industrial applications.
Frequently Asked Questions
Where can I buy Schneider Electric ZBY9W3B630?
You can click on the BUY or RFQ button to purchase ZBY9W3B630 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZBY9W3B630?
You can download the ZBY9W3B630 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZBY9W3B630?
Schneider Electric
