STRUTHERS-DUNN 292XCXC120MADC 3PDT relay
This is a sensitive relay with a 3PDT contact configuration rated for 5 amps. It features a plug-in mounting with an 11-pin blade connector and operates as a single side stable relay. The coil operates on low power, with requirements as low as 125mW for single poles and 375mW for three poles. It can withstand voltage ranges up to nearly four times the minimum voltage, making it suitable for various industrial applications. The relay offers quick switching with operate times around 20ms and release times of 15ms, ensuring reliable performance in control systems.
STRUTHERS-DUNN 292XCXC120MADC 3PDT relay Specifications:
- Contact Configuration: Up to 3PDT (SPDT, DPDT, 3PDT)
- Contact Material: Silver
- Contact Rating: 120/240VAC Resistive 5 Amp, 28VDC Resistive 5 Amp
- Operate Time: Max 20ms
- Release Time: Max 15ms
- Dielectric Strength: 500Vrms across open contacts, 1500Vrms between insulated points
- Insulation Resistance: 1,000 Mohms min @ 500VAC
- Coil Power: As low as 125mW (single pole), up to 375mW for 3 poles
- Coil Resistance: 1000Ω, 2500Ω, 5000Ω, 10000Ω for various types
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -40°C to +105°C
- Mounting: Plug-in with 11-pin blade connector or panel mounting
- Enclosure: Clear Polycarbonate
- Weight: 90 grams
- Life Expectancy: Electrical 100,000 cycles, Mechanical 10,000,000 cycles
- Dimensions (Inches): 0.18 x 0.02 (4.7 x 0.5 mm) for side flange mounting
Buy the Struthers Dunn Series 292 3PDT Relay: 292XCXC120MADC
Purchase the Struthers Dunn 292XCXC120MADC relay online today and benefit from high reliability, low power consumption, and versatile mounting options. This sensitive relay with 3PDT contact configuration is ideal for industrial automation, control panels, and switching applications, offering quick response times and durable construction. With a compact design and a robust enclosure, it ensures dependable performance in demanding environments. Order now and enhance your control system's efficiency with this premium relay, designed for professionals seeking quality and longevity in automation components.
Get Struthers Dunn 292XCXC120MADC today—built for precision, low power operation, and long-lasting durability.
Frequently Asked Questions
Where can I buy STRUTHERS-DUNN 292XCXC120MADC?
You can click on the BUY or RFQ button to purchase 292XCXC120MADC from an authorized STRUTHERS-DUNN distributor.
How do I troubleshoot issues or seek technical support for part 292XCXC120MADC?
You can download the 292XCXC120MADC datasheet or visit the STRUTHERS-DUNN website for support.
Who is the manufacturer of 292XCXC120MADC?
STRUTHERS-DUNN
