Turck B1N360VQ20L602LU3H1151 Industrial Inclinometer
The inclinometer B1N360V-Q20L60-2LU3-H1151 is a high-precision tilt sensor utilizing MEMS technology, designed for vertical mounting applications. It provides an accurate measuring range of 0.360 inches with excellent repeatability below 0.2% of the measuring range and linearity deviation under 0.6%. The device features dual analog voltage outputs for redundancy, with a response time of approximately 0.15 seconds. Encased in a compact, rugged plastic housing with IP68/IP69K protection, it withstands harsh industrial environments and vibration up to 55 Hz. Suitable for precise angle measurement and tilt monitoring in automation and industrial systems.
Turck B1N360VQ20L602LU3H1151 Industrial Inclinometer Specifications:
- Measuring Range: 0.360 inches
- Repeatability: < 0.2% of measuring range
- Linearity Deviation: < 0.6%
- Temperature Drift: $0.05%/K
- Resolution: < 0.14°
- Ambient Temperature: -30°C to +470°C
- Operating Voltage: 10-30 VDC
- Isolation Test Voltage: $0.5 kV
- Response Time: 0.15 seconds
- Housing Material: Plastic, PC
- Dimensions: 60 x 30 x 20 mm
- Protection Class: IP68/IP69K
- Vibration Resistance: 55 Hz, 1 mm
- Shock Resistance: 30g (11 ms)
- Electrical Connection: M12 x 1 connector
- Wire Breakage/Polarity Protection: Yes
- Outputs: 2 analog voltage outputs, 0.1-4.9 V
- Response Time: 0.15 seconds
- Mounting: Vertical
- Response Time: 0.15 seconds
Buy the Buy TURCK Inclination Sensor Part Number B1N360V-Q20L60-2LU3-H1151 Online
Purchase the TURCK B1N360V-Q20L60-2LU3-H1151 inclinometer online today and improve your industrial monitoring with its precise tilt detection. This high-quality sensor offers dual analog voltage outputs for redundancy, a compact rugged plastic housing with IP68/IP69K protection, and a quick response time of approximately 0.15 seconds. Suitable for vertical mounting, it performs reliably in harsh environments with high vibration and temperature extremes. Ensure your project benefits from accurate, dependable angle measurement with this advanced inclinometer designed for demanding industrial applications.
Order your TURCK Series B1N360V-Q20L60-2LU3-H1151 inclinometer today and enhance your automation system with reliable, high-precision tilt measurement.
Frequently Asked Questions
Where can I buy Turck B1N360VQ20L602LU3H1151?
You can click on the BUY or RFQ button to purchase B1N360VQ20L602LU3H1151 from an authorized Turck distributor.
How do I troubleshoot issues or seek technical support for part B1N360VQ20L602LU3H1151?
You can download the B1N360VQ20L602LU3H1151 datasheet or visit the Turck website for support.
Who is the manufacturer of B1N360VQ20L602LU3H1151?
Turck
