Turck BC20K40SRVP4X2 Capacitive proximity sensor
The capacitive sensor BC20-K40SR-VP4X2 is designed for non-contact detection of metallic and non-metallic objects, offering a sensing range of 20 mm for flush mounting and 30 mm for non-flush mounting. It features a smooth plastic ABS housing with a diameter of 40 mm and a sensing face of similar material. The sensor operates on 10-65 VDC, utilizes a 4-wire PNP changeover contact output, and includes protective features such as short-circuit, reverse polarity, and wire breakage protections. It boasts vibration and shock resistance, a protective class of IP67, and precise adjustment via potentiometer, making it ideal for industrial applications requiring reliable object detection with high precision and durability.
Turck BC20K40SRVP4X2 Capacitive proximity sensor Specifications:
- Sensing range: 20 mm (flush mounting), 30 mm (non-flush mounting)
- Hysteresis: 2...20
- Temperature drift: <£20%
- Repeatability: <2%
- Ambient temperature: -25°C to +470°C
- Operating voltage: 10-65 VDC
- Residual ripple: 5-10%
- Rated operational current: <200mA
- No-load current: <15mA
- Residual current: <0.1mA
- Switching frequency: <0.1 kHz
- Insulation voltage: 0.5 kV
- Output function: 4-wire, changeover contact, PNP
- Voltage drop: <1.8V
- Housing material: ABS plastic
- Dimensions: Diameter 40 mm, Length 90 mm
- Protection class: IP67
- Vibration resistance: 55 Hz (1 mm)
- Shock resistance: 30 g (11 ms)
- Connection: Terminal chamber, with axial and radial cable entries
- Designed for industrial automation, precise and wear-free detection
Buy the Buy Turck Capacitive Sensor Part Number BC20-K40SR-VP4X2 Online
Purchase the Turck capacitive proximity sensor BC20-K40SR-VP4X2 online today for reliable detection of metallic and non-metallic objects with high precision. Designed for industrial environments, it offers a sensing range of 20 mm for flush mounting and 30 mm for non-flush mounting, with IP67 protection to withstand harsh conditions. Its adjustable potentiometer allows fine-tuning, while various protective features ensure safety and durability. Ideal for automation systems requiring accurate, wear-free, and long-lasting object detection, making it the perfect component for your industrial needs.
Get Turck BC20-K40SR-VP4X2 today—engineered for precise, wear-free object detection in industrial automation with high durability.
Frequently Asked Questions
Where can I buy Turck BC20K40SRVP4X2?
You can click on the BUY or RFQ button to purchase BC20K40SRVP4X2 from an authorized Turck distributor.
How do I troubleshoot issues or seek technical support for part BC20K40SRVP4X2?
You can download the BC20K40SRVP4X2 datasheet or visit the Turck website for support.
Who is the manufacturer of BC20K40SRVP4X2?
Turck
