YAGEO PNP1WVJT520R47 Wirewound Resistor
This high power wirewound resistor offers reliable performance in industrial settings with ratings up to 7W. Featuring a ceramic rod wound with resistive wire, coated with green flame-proof lacquer, it ensures safety and durability. The resistor provides resistance values from 0.10Ω to 1.3KΩ with a ±5% tolerance and a temperature coefficient of +300ppm/°C. Suitable for environments with temperatures from -40°C to +200°C, it withstands overloads and features UL-94V-0 flameproof coating, making it ideal for high-power applications requiring thermal stability and robustness.
YAGEO PNP1WVJT520R47 Wirewound Resistor Specifications:
- Power Rating: 1W, 2W, 3W, 4W, 5W, 7W
- Resistance Range: 0.10Ω to 1.3KΩ
- Resistance Tolerance: ±5%
- Temperature Coefficient: +300ppm/°C
- Operating Temperature Range: -40°C to +200°C
- Flameproof Multi-layer Coating: Meets UL-94V-0
- Maximum Working Voltage: 300V
- Resistance to Overload: 10 times rated power for 5 seconds
- Insulation Resistance: >100MQ
- Solderability: 95% minimum coverage
- Environmental Resistance: Damp heat, thermal cycling, resistance to soldering heat, and solvent resistance tested
- Physical Dimensions: Vary by style; for example, PNP1WV: 10x1.0mm, PNP7WV: 25x1.0mm, with coating thickness 0.8mm
- Construction: Resistive wire wound on ceramic core with electrolytic copper end-caps
Buy the YAGEO PNP1WVJT520R47 – Reliable Wirewound Resistor for High-Power Industrial Use
Order the PNP1WVJT520R47 wirewound resistor online today and enjoy exceptional performance in high-power, high-temperature applications. With ratings up to 7W, resistance values from 0.10Ω to 1.3KΩ, and a sturdy flameproof coating, this resistor ensures safety, reliability, and thermal stability in industrial settings. Its robust construction, resistance to overload, and environmental resilience make it the ideal choice for engineers and procurement specialists seeking durable electronic components. Purchase now and experience long-lasting performance in your projects.
Get PNP1WVJT520R47 today—built for high power and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy YAGEO PNP1WVJT520R47?
You can click on the BUY or RFQ button to purchase PNP1WVJT520R47 from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part PNP1WVJT520R47?
You can download the PNP1WVJT520R47 datasheet or visit the YAGEO website for support.
Who is the manufacturer of PNP1WVJT520R47?
YAGEO
