YAGEO RC0805FR07150RL Surface Mount Resistor
The RC0805 surface-mount chip resistor by YAGEO Phicomp offers RoHS compliance and environmental friendliness with lead-free epoxy and halogen-free features. Designed for general purpose applications, it provides high reliability and PCB space efficiency. Constructed on a high-grade ceramic body with noble metal embedded resistive elements, the resistor is laser trimmed for precise resistance values. Suitable for a wide resistance range from 1Ω to 22MΩ, it supports operating temperatures from -55°C to +155°C and maximum voltages up to 300V. Available in reel packaging for bulk SMT assembly, it ensures consistent performance and durability in electronic circuits.
YAGEO RC0805FR07150RL Surface Mount Resistor Specifications:
- Type: Surface Mount Chip Resistor
- Size: 0805 (2.00 mm x 1.25 mm x 0.50 mm)
- Resistance Range: 1Ω to 22MΩ
- Tolerance: ±1% (E24), ±5% (E24/E96)
- Temperature Coefficient: ±200 ppm/°C (for 10Ω to 22MΩ), ±100 ppm/°C (for over 10Ω)
- Operating Temperature: -55°C to +155°C
- Maximum Working Voltage: 150V
- Rated Power: 1/8 W at 70°C
- Maximum Overload Voltage: 300V
- Dielectric Withstanding Voltage: 300V
- Pulse and Surge Voltage support
- Reel Packaging: 7
- 10
- 13
- Packaging Quantity: 5,000; 10,000; 20,000 units per reel
- Construction: Ceramic body with internal noble metal electrodes, overcoated with a protective epoxy, external matte tin on Ni barrier
- Marking: E-24 series; 3 digits or 4 digits for resistance value
- RoHS and Halogen Free compliant
Buy the YAGEO Series RC0805 Resistor: 150 Ohm
Purchase your YAGEO Series RC0805 surface mount resistor today online to ensure high quality, RoHS compliance, and reliable performance in your electronic assemblies. Ideal for general purpose applications, this resistor offers a wide resistance range from 1Ω to 22MΩ, supporting various circuit needs. Its robust ceramic construction with noble metal embedded resistive layer guarantees stability at temperatures from -55°C to +155°C. Available in convenient reel packaging, it is suitable for automated SMT manufacturing, ensuring precise resistance values and consistent quality for all your electronic innovations.
Order your YAGEO Series RC0805 resistor today and give your electronic projects reliable, environmentally friendly performance with high precision and durability.
Frequently Asked Questions
Where can I buy YAGEO RC0805FR07150RL?
You can click on the BUY or RFQ button to purchase RC0805FR07150RL from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part RC0805FR07150RL?
You can download the RC0805FR07150RL datasheet or visit the YAGEO website for support.
Who is the manufacturer of RC0805FR07150RL?
YAGEO
