YAGEO RC2512JK07100KL Thick Film Chip Resistor
The Yageo RC_L series resistors are general-purpose thick film chip resistors with lead-free terminations manufactured via thick film process. They feature a resistance range from 1 ohm to 100 megaohms, covering E24 and E96 decade values. These resistors are constructed on a high-grade ceramic body and are available in various standard case sizes including EIA 0075, 0100, 0201, 0402, 0603, 0805, 1206, 1210, 1218, 2010, and 2512. They are compact, saving PCB space, and rated for voltages between 10V and 200V with a maximum power dissipation of 2W. Tolerance options include ±0.1%, ±0.5%, ±1%, and ±5%. They are designed for high reliability and do not contain forbidden materials. Operating temperature ranges from -55°C to 155°C for larger sizes (RC0402 to RC2512), and from -55°C to 125°C for smaller sizes (RC0075 to RC0201).
YAGEO RC2512JK07100KL Thick Film Chip Resistor Specifications:
- Resistance Range: 1Ω to 100MΩ, covering E24 and E96 series values
- Material: Ceramic body with thick film resistive element
- Termination: Lead-free, environmentally friendly
- Case Sizes: RC0075, RC0100, RC0201, RC0402, RC0603, RC0805, RC1206, RC1210, RC1218, RC2010, RC2512
- Operating Temperature: -55°C to 155°C for sizes RC0402 to RC2512, -55°C to 125°C for sizes RC0075 to RC0201
- Rated Voltage: 10V to 200V depending on size
- Power Dissipation: Up to 2W (at 70°C), varies by size
- Tolerance: ±0.1%, ±0.5%, ±1%, ±5%
- Application: General-purpose, high reliability electronic circuits
- Compliance: RoHS compliant, halogen free
Buy the Buy Yageo Resistor Part Number RC2512JK07100KL Online
Purchase the Yageo RC2512JK07100KL thick film chip resistor today and ensure your electronic design benefits from top-tier reliability, wide resistance options up to 100 megaohms, and robust temperature tolerance from -55°C to 155°C. With lead-free environmentally friendly termination, compact size, and high power dissipation capacity, this resistor is ideal for space-constrained applications that demand precision and durability. Order online now to upgrade your electronic components with trusted quality.
Buy Yageo RC2512JK07100KL now and experience unmatched reliability and high performance in your electronic projects.
Frequently Asked Questions
Where can I buy YAGEO RC2512JK07100KL?
You can click on the BUY or RFQ button to purchase RC2512JK07100KL from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part RC2512JK07100KL?
You can download the RC2512JK07100KL datasheet or visit the YAGEO website for support.
Who is the manufacturer of RC2512JK07100KL?
YAGEO
