YAGEO SMD1812B260TF12 Overcurrent Protection Device
The SMD1812 series is a surface mount resettable overcurrent protection device rated for holding currents from 0.1A to 3.0A, ideal for USB ports, motherboards, and consumer electronics. RoHS compliant, halogen-free, with low profile design, it responds quickly to fault currents, saving board space. Suitable for applications like HDMI drives, game consoles, and general electronics, it features solder-plated copper terminals, high-temperature solderability, and comes in compact tape packaging for easy assembly. Designed to enhance circuit safety and reliability in modern electronic systems.
YAGEO SMD1812B260TF12 Overcurrent Protection Device Specifications:
- Resistance range: 0.10Ω to 3.00Ω
- Holding Current: 0.1A to 3.0A
- Maximum voltage withstand: Vinmax varies by model
- Resistance in trip state: 0.020Ω to 0.080Ω
- Terminal Material: Solder-plated Copper (Sn)
- Solderability: Meets EIA RS186-9E, ANSI J-STD-002 Category 3
- RoHS and halogen-free compliance
- Package: 178mm tape on 7 inch reel, compatible with EIA-481
- Ambient operating temperature: -55°C to +125°C
- Dimensions: Length 3.45mm, Width 3.18mm, Height 1.75mm approx.
- Application voltage ratings: up to 16V for various models
- Device type: Surface mount PTC thermistor, resettable
- Soldering: High-temperature resistant solders, suitable for wave or reflow soldering
- Agency approvals: UL, CUL, TUV certified
Buy the YAGEO SMD1812B260TF12 – Reliable Overcurrent Protection for Industrial Applications
Enhance your electronic circuits with YAGEO’s SMD1812B260TF12, a highly reliable overcurrent protection component. Its RoHS compliance, halogen-free construction, and compact design ensure easy integration into various devices like USB hubs, motherboards, and gaming consoles. Fast fault response minimizes damage, while high-temperature solderability guarantees robust performance. Packaging includes tape on reels for simple pick-and-place assembly. Trust YAGEO to deliver safety, durability, and quality in your electronic protection solutions, making your products safer and more reliable.
Get YAGEO SMD1812B260TF12 today—built for precision and long-lasting durability in circuit protection.
Frequently Asked Questions
Where can I buy YAGEO SMD1812B260TF12?
You can click on the BUY or RFQ button to purchase SMD1812B260TF12 from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part SMD1812B260TF12?
You can download the SMD1812B260TF12 datasheet or visit the YAGEO website for support.
Who is the manufacturer of SMD1812B260TF12?
YAGEO
