YAGEO TC164FR0722KL Chip Resistor
The TC164FR0722KL is a high-reliability chip resistor designed for surface-mounted applications in electronic circuits. Constructed on a ceramic body with thick film resistive elements, it features lead-free, RoHS-compliant finishes with epoxy coating for environmental protection. This resistor, rated for 1/16 W with a maximum operating temperature of +155°C, offers excellent resistance stability, low noise, and space-saving design. Suitable for precision circuitry such as SDRAM, DDRAM modules, and compact electronic devices, it ensures durability, electrical stability, and compliance with industry standards for environmentally conscious manufacturing.
YAGEO TC164FR0722KL Chip Resistor Specifications:
- Construction: Ceramic body with thick film resistive layer, laser trimmed for accuracy
- Material: Noble metal resistive element embedded in glass, covered by a second glass coating
- Size: 1/16 W power rating, rated for -55°C to +155°C operating temperature
- Environmental: RoHS compliant, lead-free, epoxy coated for protection
- Electrical: Resistance range 10Ω to 1MΩ, resistance tolerance ±1%, maximum voltage 50V, rated power 1/16 W
- Dimensions: H: 0.60 mm, W: 0.30 mm, L: 1.60 mm (typical for series)
- Soldering: Compatible with standard SMT reflow process, recommended soldering profiles specified separately
- Marking: E-24 series 3-digit code for resistance value, no marking on some types
- Certifications: RoHS compliant, UL recognized, IEC standards adhered to
- Application: Suitable for high-density PCBs, memory modules, telecom, and consumer electronics
Buy the Buy YAGEO Chip Resistor Surface Mount Part Number TC164FR0722KL Online
Order the YAGEO TC164FR0722KL chip resistor online today for dependable performance in demanding electronic circuits. Designed with high-grade ceramic, thick film resistive elements, and lead-free RoHS compliance, this compact surface-mount resistor offers excellent stability, temperature tolerance, and environmental resilience for applications like SDRAM, DDRAM modules, and precise circuitry. Its durable construction ensures longevity and consistent electrical characteristics, making it an ideal choice for high-density PCB assembly, telecom, and consumer devices. Purchase now for quick delivery and trusted quality assurance.
Buy YAGEO TC164FR0722KL now and experience unmatched reliability and performance in high-precision, space-saving resistor solutions.
Frequently Asked Questions
Where can I buy YAGEO TC164FR0722KL?
You can click on the BUY or RFQ button to purchase TC164FR0722KL from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part TC164FR0722KL?
You can download the TC164FR0722KL datasheet or visit the YAGEO website for support.
Who is the manufacturer of TC164FR0722KL?
YAGEO
