YAGEO TC164FR07680RL Chip Resistor Array
The TC164 chip resistor array offers high reliability surface-mount design suitable for various electronic and industrial applications. Constructed on a ceramic substrate with thick film resistive elements and protective overcoat, these RoHS-compliant components feature lead-free terminations. They provide precise resistance values, excellent thermal stability, and compact dimensions, making them ideal for high-density circuit assemblies such as SDRAM, DDRAM, and mobile communication devices. Available in multiple sizes with various resistance tolerances and packaging options, they are engineered for durability and ease of installation in demanding environments.
YAGEO TC164FR07680RL Chip Resistor Array Specifications:
- Construction: Ceramic substrate with thick film resistive elements
- Resistance Range: 0.01 to 97.6 KQ
- Tolerance: ±1% or ±5%
- Temperature Coefficient: Based on specific series
- Power Ratings: 1/16 W for sizes like YC122/124/162/164/248/158/358, 1/8 W for YC324
- Operating Temperature Range: -55°C to +155°C
- Max Working Voltage: V= JPR or specified maximums, typically 30V to 100V
- RoHS Compliance: Yes, with lead-free terminations
- Materials: Noble metal resistor element, glass insulation, matte tin over Ni barrier terminations
- Physical Dimensions: Varied per series, e.g., YC122 typical dimensions; detailed in datasheet
- Packaging: Paper taping reel (7” or 13”), embossed plastic tape (7” reel)
- Testing: Solderability, resistance to moisture, thermal shock, and soldering heat as per MIL-STD-202G and IEC standards
Buy the YAGEO Series TC164 Chip Resistor Array: TC164FR07680RL
Purchase the high-quality YAGEO chip resistor array online today. Designed for reliable performance in industrial and electronic equipment, these RoHS-compliant components feature lead-free terminations and precise resistance values. Available in multiple sizes and packaging options, they ensure efficient, high-density circuit assembly with excellent thermal stability and durability. Ideal for SDRAM, DDRAM, mobile devices, and consumer electronics, order now for fast delivery and secure online shopping experience.
Get YAGEO TC164 today—built for precision and long-lasting durability in demanding electronic circuits.
Frequently Asked Questions
Where can I buy YAGEO TC164FR07680RL?
You can click on the BUY or RFQ button to purchase TC164FR07680RL from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part TC164FR07680RL?
You can download the TC164FR07680RL datasheet or visit the YAGEO website for support.
Who is the manufacturer of TC164FR07680RL?
YAGEO
