YAGEO YC124JR077R5L Surface Mount Resistor Array
The YC124JR077R5L is a high-reliability surface mount chip resistor array designed for demanding electronic applications. Made with thick film process and lead-free terminations, it qualifies under AEC-Q200 standards, ensuring environmental compliance and durability. Suitable for SDRAM, DDRAM, and various computer and mobile device applications, it offers low assembly costs, RoHS compliance, and robust performance in thermal, humidity, and mechanical stress. Its compact design minimizes PCB space while providing high component and equipment reliability, making it ideal for modern electronic manufacturing.
YAGEO YC124JR077R5L Surface Mount Resistor Array Specifications:
- Type: Chip Resistor Surface Mount
- Series: YC/TC
- Resistance Range: 102 to 358 (last digits indicate ohms with multipliers)
- Tolerance: ±1% or ±5%
- Temperature Coefficient: Based on specification
- Power Rating: YC102/104 = 1/32 W, YC122/124/162/164/248/358/158T/358L/358T = 1/16 W, YC324 = 1/8 W, TC122/124/164 = 1/16 W
- Operating Temperature Range: -55°C to +125°C (YC102/104), -55°C to +155°C (others)
- Rated Voltage: Calculated from resistance value and power rating, e.g., 50V to 200V depending on series
- Construction: Ceramic substrate, metal electrodes, overcoat, laser trimmed, protected with epoxy, matte tin external termination
- Features: RoHS compliant, lead-free, halogen-free epoxy, high reliability, space-saving design
- Applications: SDRAM and DDRAM terminal, computer, mobile phones, telecom equipment
- Package: Tape reel (7'' or 13'' diameter), quantities up to 50,000 units
- Environmental Tests: Vibration, solderability, moisture resistance, thermal shock, endurance, and overload resistance
- Markings: No marking on YC102/122, alphanumeric codes for others, value indicated by digits and zeros
- Dimensions: Refer to datasheet for specific series, typically small and suitable for compact PCB layouts
Buy the YAGEO YC124JR077R5L – Reliable Surface Mount Resistor Array for Industrial Applications
Order the YAGEO YC124JR077R5L resistor array online today to enhance your electronic designs with superior reliability, RoHS compliance, and space-efficient performance. This surface mount component is ideal for high-frequency and high-density applications in computers, mobile devices, and telecom systems. With proven thermal, humidity, and mechanical resilience, it ensures your product’s durability and compliance with strict environmental standards. Enjoy fast delivery and competitive pricing by purchasing directly from authorized distributors online.
Buy YAGEO YC124JR077R5L now and experience unmatched reliability and performance in your electronic projects.
Frequently Asked Questions
Where can I buy YAGEO YC124JR077R5L?
You can click on the BUY or RFQ button to purchase YC124JR077R5L from an authorized YAGEO distributor.
How do I troubleshoot issues or seek technical support for part YC124JR077R5L?
You can download the YC124JR077R5L datasheet or visit the YAGEO website for support.
Who is the manufacturer of YC124JR077R5L?
YAGEO
