3M 1512127422TH female header connector
The 3M 1512127422TH is a 12-pin straight female header with solder tails, ideal for wire-to-board connections in electronic assemblies. Made from high-temperature UL 94V-0 cured glass-filled LCP insulator, it supports lead-free solder processes, ensuring reliable electrical contact. Its rugged copper alloy contact with gold over matte tin plating offers excellent durability and corrosion resistance. The component withstands temperatures from -55°C to +105°C, with a maximum soldering temperature of 260°C. Designed to minimize PCB space, it features end and side stackable options for flexible mounting in complex electronic applications.
3M 1512127422TH female header connector Specifications:
- Material: Glass-filled LCP UL 94V-0
- Contact Material: Copper Alloy
- Contact Plating: 50 um Nickel / 30 um Gold / 200 um Matte Tin
- Temperature Rating: -55°C to +105°C
- Maximum Soldering Temperature: 260°C
- Insulation Resistance: > 1 x 10^9 Ω at 250 VDC
- Current Rating: 1A per pin
- Voltage Rating: 500 V at sea level
- Pin Count: 12
- Pin Length: 0.130 inch / 3.3 mm
- Physical Dimensions: Length (varies per model), pitch 2 mm
- Environmental Compliance: RoHS
Buy the 3M 1512127422TH – Reliable Female Header for Industrial Applications
Enhance your electronic assemblies with the reliable 3M 1512127422TH female header featuring 12 solder tails. Crafted from high-temperature glass-filled LCP insulator, it supports lead-free soldering processes. The copper alloy contacts are gold over matte tin plated, ensuring excellent durability and corrosion resistance. With a temperature range from -55°C to +105°C and a maximum solder temperature of 260°C, this component minimizes PCB space, offering end and side stackable options for flexible mounting in complex assemblies. Perfect for secure wire-to-board connections.
Order your 3M 1512127422TH series female header today and give your electronic projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy 3M 1512127422TH?
You can click on the BUY or RFQ button to purchase 1512127422TH from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 1512127422TH?
You can download the 1512127422TH datasheet or visit the 3M website for support.
Who is the manufacturer of 1512127422TH?
3M
