3M 344889114 Ribbon Cable Socket
Preassembled wiremount for .050-inch pitch cable, 0.100-inch size, designed for reliable electrical connections in wiring assemblies. It features glass-filled polyester insulation with UL 94V-0 flammability rating, phosphor bronze contacts with 50 micro-inch nickel underplating and 30 micro-inch gold overlay, accommodating 26 and 28 AWG stranded wires. The socket provides effective strain relief, dual polarization, and optional pull tabs, making it suitable for automated and manual assembly. Rated for 30 V, 1 A, with voltage resistance up to 1000 V at sea level and temperature tolerance from -55°C to +105°C.
3M 344889114 Ribbon Cable Socket Specifications:
- Material: Glass Filled Polyester (PBT), UL 94V-0 flammability rating
- Contact Material: Phosphor Bronze with 50 micro-inch Nickel and 30 micro-inch Gold plating
- Wire Accommodation: 26 and 28 AWG stranded wires
- Voltage Rating: 30 V, Withstanding Voltage: 1000 V at sea level
- Current Rating: 1 A at 30°C, Temperature Range: -55°C to +105°C
- Size: .100 inch x .100 inch for .050 inch pitch cable
- Connector Features: Preassembled, dual polarization, optional pull tabs, strain relief
- Physical Dimensions: Height approximately 1.25–1.50 inches, Widths vary by configuration
- Certifications: UL listed (E68080), RoHS compliance applicable
- Environmental Resistance: Suitable for shipment and unplugging applications, resistant to elevated temperatures and mechanical stress
Buy the 3M Series 891 IDC Ribbon Cable Socket: 344889114
Order the 3M Series 891 IDC Ribbon Cable Socket online today and ensure your wiring projects benefit from reliable, high-quality connections. Designed with preassembled features, dual polarization, and optional pull tabs, this socket simplifies installation in automated and manual assembly setups. Its rugged construction with UL 94V-0 polyester and gold-plated contacts guarantees durability and excellent conductivity. Suitable for .050-inch pitch ribbon cables, it supports a voltage of 30 V and a current of 1 A. Enhance your wiring efficiency and performance by purchasing this dependable component online now.
Buy 3M Series 891 IDC Ribbon Cable Socket for reliable electrical connections and easy assembly today.
Frequently Asked Questions
Where can I buy 3M 344889114?
You can click on the BUY or RFQ button to purchase 344889114 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 344889114?
You can download the 344889114 datasheet or visit the 3M website for support.
Who is the manufacturer of 344889114?
3M
