3M 35058034 Electronics Connector
This high-quality connector series offers versatile surface-mount and through-hole options with a 0.100-inch pitch, suitable for compact electronic assemblies. Designed for reliable connections, these connectors feature molded-on construction with integral strain relief, low profile for close component stacking, and gold or matte tin plating options. They are rated for 1 A current, with an insulation resistance exceeding 5 x 10^9 Q at 500 V, and operate from -55°C to +105°C, making them ideal for tight electronic circuit integration requiring durability and precision.
3M 35058034 Electronics Connector Specifications:
- Insulation Material: Glass Filled Polyester (PBT)
- Flammability: UL 94V-0
- Color: Gray
- Contact Material: Copper Alloy (C521)
- Plating: Nickel underplating with Matte Tin or Gold
- Wire Accommodation: 26 and 28 AWG, Solid or Stranded
- Current Rating: 1 A
- Insulation Resistance: > 5 x 10^9 Q at 500 V
- Withstanding Voltage: 1000 V AC at sea level
- Temperature Rating: -55°C to +105°C
- Physical Dimensions: see technical drawings for hole pattern and connector size
- Certifications: UL File No.: E68080
Buy the 3M Series 877 Connector: 35058034
Purchase the 3M Series 877 connector now for your electronic applications. Featuring a low profile, durable molded-on construction, and options for surface-mount or through-hole installation, this connector ensures secure, reliable connections in tight spaces. With a 0.100-inch pitch, gold or matte tin plating, and a rated current of 1 A, it is suitable for various circuit board assemblies. Ensure high performance with this versatile, easy-to-mount connector designed for professional use and long-term reliability.
Order your 3M Series 877 connector today and ensure reliable, space-saving connections for your electronic projects with high-quality molded design.
Frequently Asked Questions
Where can I buy 3M 35058034?
You can click on the BUY or RFQ button to purchase 35058034 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 35058034?
You can download the 35058034 datasheet or visit the 3M website for support.
Who is the manufacturer of 35058034?
3M
