3M 891200001 Ribbon Cable Socket
Preassembled wiremount connector for .050 inch pitch cable, 0.100 inch size, designed for reliable electrical connections in wire-to-board applications. Made from glass filled polyester with UL 94V-0 flammability rating, it features phosphor bronze contacts with nickel and gold plating for corrosion resistance, accommodating 26 and 28 AWG stranded wires. This connector supports current ratings up to 1,000 V at sea level, with a temperature range of -55°C to +105°C. Its dual polarization and optional centerbump ensure proper orientation and secure mating, making it ideal for electrical and electronic systems demanding durability and precision.
3M 891200001 Ribbon Cable Socket Specifications:
- Material: Glass Filled Polyester (PBT)
- Flammability: UL 94V-0
- Color: Gray
- Contact Material: Phosphor Bronze
- Plating: Nickel and Gold
- Wire Range: 26 and 28 AWG Stranded
- Current Rating: Up to 1,000 V at Sea Level
- Temperature Rating: -55°C to +105°C
- Dimensions: .100” x .100” pitch, assembled height varies with strain relief, typical 1.25" to 1.50"
- UL File No.: E68080
- Contact Quantity: 1
- Recessed for cable exit, dual polarization options, optional centerbump
- Suitable for wire applications requiring reliable electrical connections in compact spaces
Buy the Buy 3M IDC Ribbon Cable Socket Part Number 891200001 Online
Experience the convenience of purchasing the high-quality 3M IDC Ribbon Cable Socket online. This preassembled connector features a .100 inch pitch and is crafted from durable glass filled polyester, rated UL 94V-0 for safety. Its gold-plated contacts ensure reliable electrical performance for wire-to-board applications, supporting wires from 26 to 28 AWG. Designed for a wide temperature range of -55°C to +105°C, it guarantees longevity and consistent performance in demanding electronic and electrical assemblies. Order now for efficient, secure, and high-performance connections.
Get 3M IDC Ribbon Cable Socket 891200001 today—designed for reliable, durable wire-to-board electrical connections with secure polarization features.
Frequently Asked Questions
Where can I buy 3M 891200001?
You can click on the BUY or RFQ button to purchase 891200001 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 891200001?
You can download the 891200001 datasheet or visit the 3M website for support.
Who is the manufacturer of 891200001?
3M
