3M 9298700110RA Pin Strip Header
The 3M™ Pin Strip Header Single and Dual Row from the 929 Series offers reliable electrical connections suitable for industrial applications. Featuring 0.100” and 0.235”/0.318” mating lengths, these headers are available in straight and right-angle configurations with solder tails. They are constructed with high temperature PCT or PBT insulators, copper alloy contacts with nickel underplating, and optional gold, matte tin, or tin-lead plating. Designed for wave or IR soldering, these headers provide board pin retention and board edge mounting for versatile assembly and secure connections in demanding environments.
3M 9298700110RA Pin Strip Header Specifications:
- Insulation Material: PBT or High Temperature PCT
- Flammability: UL 94V-0
- Color: Black
- Contact Material: Copper Alloy
- Plating Options: Gold, Matte Tin, Tin-Lead
- Current Rating: 2.5A
- Insulation Resistance: >5x 10^6Ω at 500V
- Withstanding Voltage: 1500V AC at Sea Level
- Temperature Rating: -40°C to +105°C
- Process Rating: 260°C (PCT), maximum insulator temperature 191°C (Solder Wave Process)
- Level: Level 1 (per J-STD-020C)
- Dimensions: As per mating length, .100” and .235”/.318” options, straight and right angle configurations
- Board Edge Mount: 2.050 mm ± 0.003
- Board Pin Retention: Optional
Buy the 3M 929 Series – Reliable Electrical Headers for Industrial Applications
Enhance your electronic assemblies with 3M’s durable Pin Strip Header from the 929 Series. Perfect for industrial applications, these headers feature high-temperature insulators, gold, tin, or tin-lead plating options, and are suitable for wave or IR soldering. With both straight and right-angle options, they provide secure connections, board pin retention, and reliable performance even in challenging environments. Purchase online today to ensure quality and efficiency in your manufacturing process.
Order your 3M Series 929 Pin Strip Header today and equip your electronic projects with dependable, high-temperature headers designed for demanding industrial environments.
Frequently Asked Questions
Where can I buy 3M 9298700110RA?
You can click on the BUY or RFQ button to purchase 9298700110RA from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part 9298700110RA?
You can download the 9298700110RA datasheet or visit the 3M website for support.
Who is the manufacturer of 9298700110RA?
3M
