3M ATG700 Double Coated Tape
3M ATG700 Double Coated Tapes are designed for applications requiring high initial tack and strong bonding. The synthetic rubber adhesive bonds effectively to metals, papers, paints, and plastics. The film carrier enhances dimensional stability and facilitates easy handling during slitting and die-cutting. These tapes are suitable for general industrial mounting, joining, and splicing, and are FDA compliant for indirect food contact, making them ideal for a wide range of industrial and commercial uses.
3M ATG700 Double Coated Tape Specifications:
- Faceside Adhesive: 760
- Backside Adhesive: 760
- Carrier: HDPE3
- Liner Color: Green plaid, 60#
- Tape Thickness: 0.002 in. (0.051 mm)
- Liner Thickness: 0.006 in. (0.15 mm)
- Adhesion to stainless steel (15 min RT): 93 Oz./in. (101 N/100 mm)
- Adhesion to stainless steel (72 hr RT): 81 Oz./in. (88 N/100 mm)
- Adhesion to stainless steel (72 hr 158°F): 126 Oz./in. (137 N/100 mm)
- Adhesion to Polyester: 89 Oz./in. (97 N/100 mm)
- Adhesion to Polypropylene: 82 Oz./in. (89 N/100 mm)
- Shear Strength (1000 grams at 72°F): 10,000 min.
- Shear Strength (500 grams at 158°F): 1773 min.
- High Temperature Operating Range: 120°F (49°C)
- Available Lengths: 36 yds. (33 m), 180 yds. (165 m), 360 yds. (329 m)
- Available Widths: 1/4 in. (6.35 mm) to 26 in. (660 mm)
- Slitting Tolerance: ± 1/32 in. (0.8 mm)
- Core Size: 3.0 in. (76.2 mm)
- FDA Compliance: Compliant with 21 CFR 175.105 and 21 CFR 177.1520
Buy the ATG700 3M Double Coated Tape | myMectronic
Securely purchase 3M ATG700 Double Coated Tape online for reliable performance in your industrial applications.
Buy Now
Frequently Asked Questions
Where can I buy 3M ATG700?
You can click on the BUY or RFQ button to purchase ATG700 from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part ATG700?
You can download the ATG700 datasheet or visit the 3M website for support.
Who is the manufacturer of ATG700?
3M
