3M N25266003RB Low Profile Connector
This low-profile, surface-mount technology connector from the 2500 Series features both straight and right-angle through-hole variants with .100 inch pitch. Made from glass-filled polyester or high-temperature PCT insulator, it offers UL 94V-0 flammability rating, and is available with gold, matte tin, or black high-temp insulator options. The connector supports current ratings up to 5 A per contact, with insulation resistance exceeding 10^12 ohms at 500 V, and withstands temperatures from -55°C to +105°C. It includes optional polarization features, mounting options, and is suitable for high-reliability industrial applications.
3M N25266003RB Low Profile Connector Specifications:
- Insulator Material: Glass Filled Polyester or High Temp PCT
- Flammability: UL 94V-0
- Color: Gray or Black
- Contact Material: Copper Alloy
- Plating: Gold, Matte Tin, or Black High Temp Insulator
- Current Rating: 5 A per contact, 3 A on six contacts
- Insulation Resistance: > 1 x 10^12 ohms at 500 V
- Withstanding Voltage: 1000 V at sea level
- Temperature Rating: -55°C to +105°C
- Process Temperature: 260°C for high-temp PCT, 191°C for PBT
- Moisture Sensitivity Level: 1
- Handling: Suitable for reflow soldering with assembly options
- Connector Series: 2500 Series, with options for straight, right angle, surface mount, and through-hole
- Additional features: polarization notches, optional retainer clips, and vacuum caps for control
- Certifications: UL Listed
Buy the 3M Series 2500 Low Profile Connectors: N25266003RB
Discover the high-reliability 3M Series 2500 low-profile connector, designed for space-saving applications with optional polarization and retainer features. Perfect for high-temperature environments, this connector offers excellent electrical performance with insulation resistance exceeding 10^12 ohms, current ratings up to 5 A per contact, and temperature tolerance from -55°C to +105°C. Available in surface-mount and through-hole variants with various plating options, it ensures durable, secure connections suitable for industrial, automation, and electronic assembly needs. Shop online now for fast, reliable delivery.
Buy 3M Series 2500 low-profile connectors now and experience robust, reliable connections with versatile mounting options and high-temperature performance.
Frequently Asked Questions
Where can I buy 3M N25266003RB?
You can click on the BUY or RFQ button to purchase N25266003RB from an authorized 3M distributor.
How do I troubleshoot issues or seek technical support for part N25266003RB?
You can download the N25266003RB datasheet or visit the 3M website for support.
Who is the manufacturer of N25266003RB?
3M
