ABB A163010110V50HZ Contactor
The compact AS contactor range offers a space-efficient design that helps optimize equipment layout while providing reliable, cost-effective, and time-saving switching solutions. These block-type, three-pole contactors feature built-in normally open auxiliary contacts connected to A40, with options for front and side-mounted auxiliary contact blocks. They are designed for quick mounting on standard DIN rails, with terminals supplied in an open position and clearly marked according to IEC 60947-1, EN 50005, and NEMA standards.
ABB A163010110V50HZ Contactor Specifications:
- Product Width: 44mm
- Product Depth: 74mm
- Product Height: 74mm
- Weight: 0.34 kg
- Number of Main Contacts: 3 NO
- Number of Auxiliary Contacts: 1 NO
- Control Voltage: 110V 50Hz / 110-120V 60Hz
- Rated Operational Voltage: 690 V AC / 220 V DC
- Rated Current: 16A (IEC 60947-5-1)
- Coil Consumption: 8.2 V-A (approximate average hold), 74 V-A (approximate pull-in)
- Operate Time: 10-26 ms
- Degree of Protection: According to IEC 60529
- Connection Terminals: Flexible 0.75-2.5 mm², Rigid 1-4 mm²
- Standards: IEC 947-1 / 947-4-1, EN 60 947-1, EN 60 947-4-1, UL/CSA, VDE
- Maximum Breaking Capacity: 21.5 kvar at 690 V, 16 A
- Electrical Durability: 10 million operations
- Environmental Temperature: -25°C to +55°C
- Certifications: UL, CSA, RINA, DNV, RoHS
Buy the Voksi A16-30-10 U– Reliable Contactor for Industrial Applications
Purchase the Voksi A16-30-10 contactor online now to ensure reliable motor control and switching efficiency. Designed for 3-phase motor applications, it offers quick installation with DIN rail compatibility and complies with international standards like IEC 60947-4-1 and UL. Its compact size saves space in control panels while providing high durability for industrial environments. Secure your supply of this cost-effective contactor today and optimize your automation setup with proven quality and easy access through our online store.
Order your Voksi Series A16-30-10 contactor today and experience dependable, space-saving switching solutions for your industrial needs.
Frequently Asked Questions
Where can I buy ABB A163010110V50HZ?
You can click on the BUY or RFQ button to purchase A163010110V50HZ from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part A163010110V50HZ?
You can download the A163010110V50HZ datasheet or visit the ABB website for support.
Who is the manufacturer of A163010110V50HZ?
ABB
