ABB A753011230V50HZ 3-Pole Contactor
The A75-30-11 is a 3-pole block contactor suitable for controlling 3-phase motors up to 690 V AC / 1000 V AC or 220 V DC. It features 3 main poles and 2 built-in auxiliary contacts, with front and side-mounted add-on auxiliary contact blocks. AC operated with laminated magnet circuit, it supports various accessories and is suitable for applications like motor control, switching power circuits, isolation, capacitor switching, and lighting. Designed for industrial environments, it offers reliability, durability, and ease of installation in control panels.
ABB A753011230V50HZ 3-Pole Contactor Specifications:
- Product Main Type: Block Contactor
- Product Name: 3-Pole Contactor
- Rated Operating Voltage: 230-240V 50Hz / 240-260V 60Hz
- Rated Frequency: 50/60 Hz
- Rated Breaking Capacity AC-3: 70 kW at 440-690 V
- Rated Operational Current AC-1: 8 x le AC-3, 10 x le AC-15
- Rated Operational Current AC-3: 85-125A depending on model and temperature
- Rated Control Circuit Voltage (U.): 24-440 V AC/DC
- Rated Short-time Withstand Current: 650 A at 40°C
- Degree of Protection: IP20
- Ambient Air Temperature: -25°C to +55°C (with thermal relay), -60°C to +80°C (without relay), or other temperature ranges based on version
- Dimensions: Width 108 mm, Height 110 mm, Depth 82 mm
- Material: Steel, copper contacts
- Connecting Terminals: Screw type, compatible with flexible or rigid cables
- Certifications: IEC, CE, UL, CSA, GOST, RoHS compliant
- Maximum Mechanical Switching Frequency: 600 cycles/hour
- Maximum Electrical Switching Frequency: 150 cycles/hour
- Mounting: Panel mount, standard DIN rail compatibility
- Environmental Standards: IEC 60068-2-30, IEC 60068-2-11
Buy the ABB A75-30-11 – Reliable Contactor for Industrial Applications
Purchase the ABB A75-30-11 online today to ensure reliable control of your industrial motors and power circuits. This high-quality block contactor offers robust performance with easy installation, extensive certifications, and compatibility with a wide range of accessories. Whether for switching power supplies, controlling lighting, or capacitor switching, this contactor provides safety, durability, and efficiency. Order now and optimize your control panel systems with this trusted industrial component, backed by high standards and excellent warranty support. Enjoy fast shipping and dedicated customer service for all your automation needs.
Buy ABB A75-30-11 now and experience unmatched reliability and performance in your motor control and switching needs.
