ABB ACSCPC Variable Frequency Drive
The ACS310 is a compact, versatile general purpose drive designed for variable torque applications such as pumps and fans. It offers easy installation, fast commissioning with preprogrammed macros, and energy-efficient features including pump cleaning and PFC control. The drive supports multi-pump and fan operation, remote monitoring via Ethernet, and built-in communication protocols like Modbus. Its space-saving design suits cabinet mounting, while robustness and automatic fault reset ensure reliable long-term operation in industrial environments. Suitable for a wide power range from 0.37 to 22 kW, it enhances system performance and reduces maintenance costs.
ABB ACSCPC Variable Frequency Drive Specifications:
- Power Range: 0.37 to 22 kW (0.5 to 30 hp)
- Input Voltage: 200-240 V AC ±10%, 380-480 V AC ±10%
- Frequency: 48 to 63 Hz, Adjustable up to 500 Hz
- Ambient Temperature: -10 to +50 °C, no frost
- Protection Class: IP20 standard, optional NEMA 1 enclosure
- Analog Inputs: 2 (0-10 V, ±10 V, 4-20 mA, ±20 mA)
- Analog Output: 0-20 mA (load < 500 Ω)
- Digital Inputs: 5, 12-24 V DC, PNP/NPN
- Relay Output: 1, max 250 V AC/30 V DC, 0.5 A
- Communication: Embedded Modbus RTU, optional Ethernet (SREA-01)
- Motor Control Method: Scalar U/f, with energy optimization
- Enclosure: IP20, optional NEMA 1, color NCS 1502-Y/RAL 9002
- Dimensions & Weight: Varies by frame; typical cabinet-mounted approx 169x202x239 mm, weight around 4.4 kg
- Standards: IEC 61800-3, EN 55011, UL, CE, RoHS, ISO 9001 & 14001
Buy the ABB Series ACS310 Power Drive: ACSCPC
Purchase the ABB Series ACS310 Variable Frequency Drive today to optimize your pumps and fans with energy-efficient control, simple installation, and remote monitoring. This compact drive supports multi-pump operation, features preprogrammed macros for easy setup, and ensures reliable long-term performance. The integrated communication protocols like Modbus RTU and optional Ethernet facilitate seamless integration into your automation system. Designed for a wide range of power applications from 0.37 to 22 kW, it reduces energy costs, minimizes maintenance, and enhances process control. Invest today for efficient and dependable system operation.
Order your ABB Series ACS310 power drive today and experience reliable performance, easy setup, and energy savings for your industrial pump and fan systems.
