ABB S201D63 Miniature Circuit Breaker
The system pro M compact S200 miniature circuit breaker is a current-limiting device designed for residential, commercial, and industrial applications. It features two tripping mechanisms: delayed thermal for overload protection and electromechanical for short circuit protection. Rated for 63A at 230/400 V AC, it complies with IEC, UL, and CSA standards, offering reliable circuit interruption with a breaking capacity up to 6kA. Compact and space-saving, it is suitable for DIN rail mounting, with optional auxiliary contacts available for additional functionality.
ABB S201D63 Miniature Circuit Breaker Specifications:
- Number of Poles: 1
- Tripping Characteristic: D
- Rated Current: 63A
- Rated Operational Voltage: 230/400 V AC
- Rated Frequency: 50/60Hz
- Rated Short-Circuit Capacity: 6kA
- Energy Limiting Class: 3
- Rated Impulse Withstand Voltage: 6.2kV @ sea level
- Maximum Insulation Voltage: 440 V
- Rated Operating Voltage: 253 V AC
- Housing Material: RAL 7035 Insulation group II, black, sealable
- Degree of Protection: IP40 in enclosure
- Mechanical Endurance: 20,000 cycles
- Electrical Endurance: 10,000 AC cycles
- Terminal Type: Screw terminals
- Connecting Capacity: Flexible 0.75…25 mm², Stranded 0.75…35 mm²
- Tightening Torque: 2.8 Nm
- Mounting on DIN Rail: TH35-15 / TH35-7.5 IEC 60715
- Certifications: IEC/EN 60898-1, IEC/EN 60947-2, UL 1077, CSA
- Standards: IEC, UL, CSA compliant
- Dimensions: Depth 69mm, Height 88mm, Width 17.5mm
- Weight: 0.125 kg
Buy the Buy General Electric Miniature Circuit Breaker Part Number S201D63 Online
Get your reliable 63A miniature circuit breaker online today from our extensive selection. Designed for residential, commercial, and industrial applications, this device features dual trip mechanisms for overload and short circuit protection, ensuring safe and efficient operation. It is IEC, UL, and CSA certified, offering a maximum short-circuit capacity of 6kA. Compact and easy to install on DIN rails, it provides long-lasting durability with thousands of mechanical and electrical cycles. Enhance your electrical system's safety now by ordering online and enjoy fast, secure delivery to meet your project needs.
Order your General Electric Series S200 63A circuit breaker today and ensure your electrical safety with reliable protection in your projects.
