ABB S201MD16 Miniature Circuit Breaker
The miniature circuit breaker System pro M compact S200M provides reliable overload and short circuit protection with rated currents up to 16A. It features D characteristic tripping for sensitive overload detection and quick short circuit response. Suitable for residential, commercial, and industrial applications, it includes screw terminals, UL/CSA approval, and IP40 protection. Its compact size (69mm x 88mm x 17.5mm) allows easy DIN rail mounting in diverse environments, with a rated operational voltage of 230/400 V AC.
ABB S201MD16 Miniature Circuit Breaker Specifications:
- Number of Poles: 1
- Tripping Characteristic: D
- Rated Current (In): 16A
- Rated Operational Voltage: 230/400 V AC
- Rated Short-Circuit Capacity (Icn): 10 kA at 230/400 V AC
- Rated Ultimate Short-Circuit Breaking Capacity (Icy): 25 kA
- Rated Service Short-Circuit Breaking Capacity (Ics): 18.8 kA
- Rated Frequency: 50/60 Hz
- Rated Impulse Withstand Voltage: 6.2 kV @ sealed)
- Maximum Insulation Voltage: 440 V
- Housing Material: Insulation group II, RAL 7035, black
- Degree of Protection: IP40
- Terminal Type: Screw Terminals
- Connecting Capacity: Busbar 10/10 mm², flexible with ferrule 0.75-25 mm²
- Tightening Torque: 2 Nm
- Mounting on DIN Rail: IEC 60715 TH35-7.5 or TH35-15
- Standards: IEC/EN 60898-1, IEC/EN 60947-2
- Electrical Endurance: 20,000 cycles
- Mechanical Endurance: 20,000 cycles
Buy the Generic 2CDS271001R0161 – Reliable Circuit Protection for Industrial Applications
Purchase the reliable miniature circuit breaker designed for safe overload and short circuit protection. With a rated current of 16A, D characteristic trip, and easy DIN rail mounting, it suits residential, commercial, and industrial needs. UL/CSA approved and IP40 rated, this compact device ensures optimal safety and performance. Its robust construction withstands electrical endurance of 20,000 cycles and mechanical durability, making it an ideal choice for professionals requiring dependable circuit protection in various settings. Order online now for fast delivery and assured quality.
Get General Electric S201M-D16 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy ABB S201MD16?
You can click on the BUY or RFQ button to purchase S201MD16 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S201MD16?
You can download the S201MD16 datasheet or visit the ABB website for support.
Who is the manufacturer of S201MD16?
ABB
