ABB S201MD25 Miniature Circuit Breaker
The miniature circuit breaker is designed for reliable overload and short circuit protection in residential, commercial, and industrial applications. It features a D trip mechanism, rated current of 25A, and complies with IEC/EN standards. Its compact size allows for easy installation on DIN rails, with screw terminals and a high breaking capacity up to 10 kA at 230/400 V AC. The product has a rated operational voltage of 230 V AC, and includes features like IP40 protection, a long electrical endurance of 20,000 cycles, and a maximum operating voltage of 253 V AC, making it suitable for various electrical systems.
ABB S201MD25 Miniature Circuit Breaker Specifications:
- Number of Poles: 1
- Tripping Characteristic: D
- Rated Current: 25A
- Rated Operational Voltage: 230/400 V AC
- Rated Short-Circuit Capacity: 10 kA at 230/400 V AC
- Rated Ultimate Short-Circuit Breaking Capacity: 25 kA
- Rated Service Short-Circuit Breaking Capacity: 18.8 kA
- Rated Frequency: 50/60 Hz
- Maximum Operating Voltage: 253 V AC
- Rated Impulse Withstand Voltage: 6.2 kV @ sealing
- Housing Material: Insulation Group II, RAL 7035, black
- Degree of Protection: IP40
- Electrical Endurance: 20,000 cycles
- Mechanical Endurance: 20,000 cycles
- Terminal Type: Screw Terminals
- Mounting on DIN Rail: IEC 60715 TH35-7.5 or TH35-15
- Tightening Torque: 2 Nm
- Conductor Capacity: Busbar 10 / 10 mm², flexible ferrule 0.75-25 mm², rigid 0.75-35 mm²
- Standards: IEC/EN 60898-1, IEC/EN 60947-2
Buy the Eaton Series S200M Miniature Circuit Breaker: 2CDS271001R0251
Experience reliable electrical protection with the Eaton Series S200M miniature circuit breaker. Designed for quick installation on DIN rails, it features a D trip characteristic, 25A rated current, and high short-circuit capacity up to 10 kA at 230/400 V AC. Its compact form, IP40 rating, and durable construction make it ideal for residential, commercial, and industrial systems. Easy to reset and maintain, this breaker ensures long-lasting protection and compliance with international standards. Buy online now for efficient and secure electrical management.
Get Eaton Series S200M 25A mini circuit breaker today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy ABB S201MD25?
You can click on the BUY or RFQ button to purchase S201MD25 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S201MD25?
You can download the S201MD25 datasheet or visit the ABB website for support.
Who is the manufacturer of S201MD25?
ABB
