ABB S204C20 Miniature Circuit Breaker
The miniature circuit breaker system pro M compact S200 provides reliable overload and short circuit protection with current limiting capabilities. It features dual tripping mechanisms—delayed thermal for overloads and electromechanical for short circuits—creating a highly effective safety device for residential, commercial, and industrial applications. Compliant with IEC/EN 60898-1, IEC/EN 60947-2, UL 1077, and CSA standards, it offers various configurations, breaking capacities up to 6 kA, rated currents to 20A, and features like bottom mounting auxiliary contacts. Its robust design ensures electrical endurance of 20,000 cycles, with a compact form factor suitable for DIN rail mounting in versatile environments.
ABB S204C20 Miniature Circuit Breaker Specifications:
- Number of Poles: 4
- Rated Current (In): 20A
- Rated Operational Voltage: 400 V AC (IEC 60898-1), 440 V AC (IEC 60947-2)
- Breaking Capacity: up to 6 kA at 230/400 V AC
- Rated Short-Circuit Capacity (Icn): 6 kA (AC), 20 kA (230 V AC)
- Rated Ultimate Short-Circuit Breaking Capacity (Icu): 20 kA
- Rated Service Short-Circuit Breaking Capacity (Ics): 15 kA
- Energy Limiting Class: Not specified
- Overvoltage Category: III
- Pollution Degree: 3
- Rated Impulse Withstand Voltage: 6 kV (AC) / 6.2 kV (Sealecel)
- Insulation Group: II, RAL 7035, black
- Degree of Protection: IP40 in enclosure with cover
- Electrical Endurance: 20,000 cycles
- Mechanical Endurance: 20,000 cycles
- Terminal Type: Screw terminals
- Connecting Capacity: Busbar 10 / 10 mm², flexible 0.75–25 mm², rigid 0.75–35 mm², stranded 0.75–35 mm²
- Tightening Torque: 2.8 Nm (UL/CSA: 25 in-lb)
- Mounting: DIN rail TH35-15 / TH35-7.5, any position
- Standards: IEC/EN 60898-1, IEC/EN 60947-2, UL 1077
- Screw Terminal: Failsafe bi-directional cylinder-fit
- Dimensions: Depth 69mm, Height 88mm, Width 70mm
- Weight: 0.5 kg
Buy the Buy Schneider Electric Miniature Circuit Breaker Part Number S204C20 Online
Protect your electrical infrastructure with the Schneider Electric Miniature Circuit Breaker. Designed for reliable overload and short circuit protection, this 4-pole device features thermal and electromechanical tripping mechanisms, rated at 20A. Its compact design allows easy DIN rail installation in residential, commercial, and industrial settings. With a high breaking capacity of up to 6 kA, it ensures safety and durability for demanding applications. Purchase this circuit breaker online today for trusted quality, easy installation, and enhanced safety in your electrical projects.
Order your Schneider Electric SeriesS200 20A 4P Manual Trip Circuit Breaker today and give your electrical systems the dependable safety and reliable overload protection they deserve.
Frequently Asked Questions
Where can I buy ABB S204C20?
You can click on the BUY or RFQ button to purchase S204C20 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S204C20?
You can download the S204C20 datasheet or visit the ABB website for support.
Who is the manufacturer of S204C20?
ABB
