ABB S204MC40 Miniature Circuit Breaker
The miniature circuit breaker S204M-C40 is a 4-pole device designed for reliable overload and short-circuit protection in residential, commercial, and industrial applications. It features a C trip characteristic, with a rated current of 40A and a rated operational voltage of 400 V AC. Constructed with durable materials, it conforms to IEC/EN standards, offering high breaking capacity up to 10 kA, with screw terminals for secure wiring. Its compact design enables versatile mounting on DIN rails, providing efficient space utilization and easy installation in control panels.
ABB S204MC40 Miniature Circuit Breaker Specifications:
- Number of Poles: 4
- Rated Current (In): 40A
- Rated Operational Voltage: 400 V AC
- Maximum Short-Circuit Capacity: 10 kA at 230/400 V AC
- Tripping Characteristic: C
- Rated Frequency: 50/60 Hz
- Rated Insulation Voltage: 440 V AC
- Rated Impulse Withstand Voltage: 6 kV
- Housing Material: Insulation Group II, RAL 7035, black, sealable
- Degree of Protection: IP40 in enclosure with cover
- Terminal Type: Screw Terminals
- Connecting Capacity: Busbar 10 / 10 mm², flexible/fixed wires 0.75...35 mm²
- Tightening Torque: 2 Nm
- Mounting: DIN Rail (IEC 60715), any position
- Standards: IEC/EN 60898-1, IEC/EN 60947-2
- Electrical Endurance: 10,000 cycles
- Mechanical Endurance: 20,000 cycles
Buy the Genuine Circuit Breaker S204M-C40 – Reliable Overload Protection for Industrial Applications
Secure your electrical systems with the high-performance S204M-C40 miniature circuit breaker. Designed for reliable overload and short-circuit protection, it features a robust construction conforming to IEC standards. Its compact 4-pole design allows seamless integration into residential, commercial, and industrial control panels. With a rated current of 40A and a breakdown capacity of up to 10 kA, it ensures safety and durability. Effortless DIN rail mounting facilitates quick installation, making it an ideal choice for modern electrical systems seeking efficiency, safety, and compliance.
Buy the S204M-C40 circuit breaker now and experience unmatched reliability, superior short-circuit protection, and versatile DIN rail mounting for your control panels.
Frequently Asked Questions
Where can I buy ABB S204MC40?
You can click on the BUY or RFQ button to purchase S204MC40 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part S204MC40?
You can download the S204MC40 datasheet or visit the ABB website for support.
Who is the manufacturer of S204MC40?
ABB
