ABB SU202MK2 Miniature Circuit Breaker
ABB SU202M-K2 Mini Circuit Breaker, rated for 2 amps and 240 VAC, with UL 489 certification. Features include a 2-pole design, K-trip characteristics, and a tripping capacity of 10 kA, making it ideal for protecting electrical circuits and systems in various industrial and commercial applications. The device features robust thermoplastic housing, a clear contact indication, and a unique twin terminal for wiring up to 35 mm². Suitable for use in North American and global markets, this breaker ensures reliable circuit protection for AC applications up to 240 VAC.
ABB SU202MK2 Miniature Circuit Breaker Specifications:
- Standards: UL 489, CSA 22.2. No. 5, IEC/EN 60947-2
- Poles: 1P, 2P
- Rated Current: 2A
- Rated Voltage: 240 Vac (phase to ground), 480Y/277 Vac (phase to phase)
- Tripping Characteristics: K-curve
- Interrupting Capacity: 10 kA
- Rated Insulation Voltage Ui: 250 Vac
- Protection Degree: IP20, IP40 in enclosure with cover
- Operating Temperature Range: -25°C to +55°C (derating applies outside this range)
- Mechanical Endurance: 20,000 operations
- Electrical Endurance: 6,000 operations (AC/DC)
- Dimensions: Approx. 88 x 69 x 175 mm
- Weight: Approx. 115 g
- Mounting: DIN rail 35 mm, quick clip mounting
- Connection: Twin terminal up to 35 mm² wiring capacity
- Protection Class: IP20/IP40 (with enclosure)
- Approval & Certification: UL 489, CSA 22.2 No. 5, IEC/EN 60947-2
Buy the ABB Series SU200 Miniature Circuit Breaker: SU202M-K2
Buy the ABB Series SU202M-K2 miniature circuit breaker online today and enjoy fast delivery. This high-performance device provides dependable circuit protection up to 2 amps at 240 VAC with UL 489 certification. Its compact design, robust thermoplastic housing, and twin terminal wiring capacity make it ideal for industrial, commercial, and residential electrical systems. With a 10 kA short-circuit breaking capacity, it ensures safety and reliability for your electrical projects. Order now and secure your electrical infrastructure with top-quality circuit protection.
Order your ABB Series SU202M-K2 miniature circuit breaker today and ensure reliable circuit protection with high interrupting capacity and easy wiring.
Frequently Asked Questions
Where can I buy ABB SU202MK2?
You can click on the BUY or RFQ button to purchase SU202MK2 from an authorized ABB distributor.
How do I troubleshoot issues or seek technical support for part SU202MK2?
You can download the SU202MK2 datasheet or visit the ABB website for support.
Who is the manufacturer of SU202MK2?
ABB
