ABL Aluminium Components BGAPP035 Thermal Interface Pad
ABL's BGAPP035 is a high-performance thermal interface pad designed for effective heat sink attachment to MPU, chipsets, and plastic-encapsulated components. Featuring excellent thermal conductivity of 0.95 W/m·K, this white aluminium-backed pad provides superior cushioning and gap filling properties for optimal heat dissipation. The adhesive system, comprising a 0.10 mm aluminium foil backing and 0.075 mm acrylic adhesive, offers high-temperature resistance, enabling secure attachment even to vertical surfaces and metal enclosures. The total thickness is 0.27 mm, ensuring reliable thermal management for electronic assemblies.
ABL Aluminium Components BGAPP035 Thermal Interface Pad Specifications:
- Backing Type: Aluminium Foil
- Backing Thickness: 0.10 mm
- Adhesive Type: Acrylic
- Adhesive Thickness: 0.075 mm
- Total Thickness: 0.27 mm
- Color: White
- Thermal Conductivity: 0.95 W/m·K
- Thermal Resistance: 0.2 °C-in²/W
- Adhesion: 15 Kg/25mm
- Holding Power at 23°C: 272 hours
- Holding Power at 130°C: >2 hours
- Intended for heat sink attachment to MPU, chipsets, plastic components, and metal enclosures
- Supplied with thermal tape for easy mounting
Buy the Buy ABL Thermal Interface Pad Part Number BGAPP035 Online
Experience reliable thermal management with the ABL BGAPP035 thermal interface pad, designed for heat sink attachment to MPU and chipsets. Featuring a high thermal conductivity of 0.95 W/m·K, this 0.27 mm thick pad offers superior gap filling and cushioning. The aluminium foil backing and acrylic adhesive provide excellent high-temperature resistance, making it suitable for attaching components to vertical heatsinks and metal enclosures. Easy to install with supplied thermal tape, ensuring optimal performance in electronic assemblies.
Buy ABL BGAPP035 high-performance thermal pad now and ensure efficient heat dissipation with excellent thermal conductivity and reliable adhesive properties.
