ABRACON ABLNOV122880MHZ Low Phase Noise XO/VCXO
The Abracon ABLNO-V-122.880MHz is a high-performance crystal oscillator designed for applications demanding ultra-low phase noise. Utilizing high 'Q' crystal technology, this XO/VCXO delivers exceptional stability and accuracy across a wide operating temperature range. Its standard LVCMOS RF output and wide frequency range (50.00MHz to 200.00MHz) make it suitable for satellite communication systems, avionics, test & measurement equipment, and low-jitter RF circuitry. The device offers frequency stability over 10 years and is Pb RoHS compliant.
ABRACON ABLNOV122880MHZ Low Phase Noise XO/VCXO Specifications:
- RF Output Frequency Range: 50.00 - 200.00 MHz
- Standard Available Frequencies: 50.00MHz, 80.00MHz, 81.92MHz, 92.16MHz, 96.00MHz, 98.304MHz, 100MHz, 104.00MHz, 106.25MHz, 120.00MHz, 122.88MHz, 125.00MHz, 150.00MHz, 155.52MHz, 156.250MHz, 200MHz
- Supply Voltage (Vdd): 3.135 - 3.465 Volts
- Current Drain @ 50MHz - 99.999MHz: 25.00 mA
- Current Drain @ 100MHz - 149.999MHz: 35.00 mA
- Current Drain @ ≥150.00MHz: 40.00 mA
- Output Load: 15 pF
- VOH: 0.9 * Vdd Volts
- VOL: 0.1 * Vdd Volts
- Output Symmetry: 45 - 55 %
- Rise & Fall Times: ≤ 3.0 ns
- Operating Temperature Range: -40 to +85 ºC
- Frequency Stability Over Temp: -12.00 to -18.00 ppm
- All Effects (Including Aging): -28.00 ppm
- Storage Temperature Range: -40 to +90 ºC
- Aging (First Year): ±2.00 ppm
- Aging (5 Years): ±5.00 ppm
- Aging (10 Years): ±7.00 ppm
- Phase Noise @ 10 Hz offset (50MHz Carrier): -90 to -82 dBc/Hz
- Phase Noise @ 100 Hz offset (50MHz Carrier): -120 to -115 dBc/Hz
- Phase Noise @ 1,000 Hz offset (50MHz Carrier): -145 to -140 dBc/Hz
- Phase Noise @ 10,000 Hz offset (50MHz Carrier): -165 to -160 dBc/Hz
- Phase Noise @ 100,000 Hz offset (50MHz Carrier): -166 to -165 dBc/Hz
- Phase Noise @ 1,000,000 Hz offset (50MHz Carrier): -166 to -165 dBc/Hz
- RMS Jitter (12kHz ~ 20MHz BW): < 100 Femto Seconds
- Frequency Adjustment Control Voltage Range: 0.0 - 3.30 Volts
- Frequency Pull Range: ±28.00 to ±55.00 ppm
- Control Port Linearity: ±10 %
Buy the ABLNO-V-122.880MHz Abracon Low Phase Noise XO/VCXO | myMectronic
Purchase the Abracon ABLNO-V-122.880MHz securely and reliably through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy ABRACON ABLNOV122880MHZ?
You can click on the BUY or RFQ button to purchase ABLNOV122880MHZ from an authorized ABRACON distributor.
How do I troubleshoot issues or seek technical support for part ABLNOV122880MHZ?
You can download the ABLNOV122880MHZ datasheet or visit the ABRACON website for support.
Who is the manufacturer of ABLNOV122880MHZ?
ABRACON
