ABRACON ASPIU2520101R0MT Power Inductor
This ultra-performance wire-wound power inductor features molded construction with shielding, ideal for motor control, switch mode power supplies, and energy-efficient lighting. It supports high currents up to 6.5A rms and high saturation currents up to 11A, with inductance up to 4.74H. Its compact footprint of 2.0 x 1.6mm or 2.5 x 2.0mm and a maximum height of 1.0mm make it suitable for space-constrained applications in industrial, robotics, medical, wearable, drone, and battery-powered environments. Operating temperature ranges from -40°C to +125°C, RoHS compliant, and MSL=1.
ABRACON ASPIU2520101R0MT Power Inductor Specifications:
- Dimensions: 2.5 x 2.0 x 1.0 mm or 2.0 x 1.6 x 1.0 mm
- Inductance Range: 0.12 µH to 4.74 H depending on model
- Maximum Current: Up to 6.5A rms, Saturation current up to 11A
- Operating Temperature: -40°C to +125°C
- Storage Temperature: -10°C to +40°C, 70% max RH
- RoHS/RoHS II compliant
- Reflow soldering: Peak temperature 260°C, Preheat 25°C to Peak, Reflow 60-120 sec
- Packaged tape & reel: 2000 pcs/reel
- MSL: 1 (Moisture Sensitivity Level)
Buy the Abracon Series Power Inductor: ASPIU2520101R0MT
Enhance your electronic designs with the Abracon power inductor supporting high currents up to 6.5A rms and saturation up to 11A. Its compact size of 2.0 x 1.6mm or 2.5 x 2.0mm fits space-constrained applications in robotics, medical devices, and energy-efficient lighting. Operating within -40°C to +125°C, RoHS compliant, with a reliable MSL=1 reflow profile ensures durability and performance. Perfect for motor control, switch mode power supplies, and battery-powered systems, order now for dependable, high-performance inductors tailored to demanding environments.
Buy Abracon ASPIU2520101R0MT power inductor now and experience unmatched reliability and performance for your high-current applications.
Frequently Asked Questions
Where can I buy ABRACON ASPIU2520101R0MT?
You can click on the BUY or RFQ button to purchase ASPIU2520101R0MT from an authorized ABRACON distributor.
How do I troubleshoot issues or seek technical support for part ASPIU2520101R0MT?
You can download the ASPIU2520101R0MT datasheet or visit the ABRACON website for support.
Who is the manufacturer of ASPIU2520101R0MT?
ABRACON
