ABRACON AWSCR737CRLBC15T3 High-frequency crystal oscillator
This crystal oscillator features a compact 4.5 x 2.0 x 1.0 mm package, RoHS compliant, and is designed for high-frequency applications from 4.00 to 12.00 MHz. It offers low resonance impedance, built-in capacitance options, and operates reliably across -40°C to 125°C. Suitable for metering systems, remote control, industrial control, and microprocessor circuits, it provides excellent stability, aging rate of max 0.2% over 10 years, and withstands voltages up to 50V DC. Its robust design ensures long-term performance in demanding industrial environments.
ABRACON AWSCR737CRLBC15T3 High-frequency crystal oscillator Specifications:
- Package Size: 4.5 x 2.0 x 1.0 mm
- Frequency Range: 4.00 - 12.00 MHz
- Standard Capacitance: 15 pF (other options: 10, 22, 30, 33, 39, 47 pF)
- RoHS/RoHS I Compliant, Pb in ceramic (exemption 7c)
- Operating Temperature Range: -40°C to +125°C
- Resonant Frequency Tolerance: ±0.5%
- Frequency Drift: Max ±0.2% over -40°C to +125°C
- Oscillator Frequency Drift: (-40°C to +125°C)
- Withstanding Voltage: 50 V DC
- Aging Rate: Max 0.2% over 10 years
- Insulation Resistance: ≥1 MΩ at +125°C
- Storage Temperature: +125°C
- Compliance: RoHS, Reflow compatible, Meets industry standards for stability and durability
Buy the Abracon AWSCR737CRLBC15T3 – Reliable Crystal Oscillator for Industrial Applications
Purchase the Abracon crystal oscillator online today to ensure your industrial circuitry benefits from high stability and precise frequency control. Designed for robust performance across extended temperature ranges, this compact 4.5 x 2.0 mm component provides low resonance impedance and built-in capacitance options for versatile applications like metering, remote control, and microprocessors. Its RoHS compliance and excellent aging characteristics make it an ideal choice for demanding industrial environments, offering reliable long-term operation and resistance to extreme temperatures. Buy now for exceptional quality.
Get Abracon AWSCR737CRLBC15T3 today—built for precision, reliability, and long-lasting stability in high-frequency industrial circuits.
Frequently Asked Questions
Where can I buy ABRACON AWSCR737CRLBC15T3?
You can click on the BUY or RFQ button to purchase AWSCR737CRLBC15T3 from an authorized ABRACON distributor.
How do I troubleshoot issues or seek technical support for part AWSCR737CRLBC15T3?
You can download the AWSCR737CRLBC15T3 datasheet or visit the ABRACON website for support.
Who is the manufacturer of AWSCR737CRLBC15T3?
ABRACON
