AIRPAX / SENSATA M556296108 Three Pole Circuit Breaker
The AIRPAX / SENSATA M55629/6-108 is a three-pole magnetic circuit breaker designed for use in Department of Defense applications. This circuit breaker offers a trip-free mechanism and auxiliary contacts for added functionality. It is characterized by specific dimensions, current ratings, voltage ratings, and interrupting capacities as detailed in MIL-PRF-55629/6G. The device includes terminals and mounting hardware, and physical item marking is optional. Refer to figures 1 and 2 for dimensional configurations and tables I-V for detailed specifications.
AIRPAX / SENSATA M556296108 Three Pole Circuit Breaker Specifications:
- Ltr: Inches
- Inches: Inches
- mm: mm
- A: 0.149-0.211
- B: 1.420-1.470
- C: 0.359-0.391
- D: 0.719-0.781
- E: 2.046-2.078
- F: 0-2.530
- G: 0.187-0.249
- H: 0.109-0.171
- J: 0.249-0.311
- K: 1.660-1.960
- L: 0-0.427
- M: 0.519-0.699
- N: 0-2.800
- P: 0-2.340
- R: 2.000-2.040
- S: 0-2.553
- T: 2.205-2.285
- A_min: 2.475
- A_max: 2.505
- B_min: 2.045
- B_max: 2.075
- C_min: 0.205
- C_max: 0.235
- D_min: 0.735
- D_max: 0.765
- E_min: None
- E_max: 2.265
- F_min: 0.167
- F_max: 0.197
- G_min: 1.423
- G_max: 1.453
- H_min: 0.535
- H_max: 0.565
- J_min: 1.921
- J_max: 2.081
- K_min: None
- K_max: 2.514
- L_min: 0.266
- L_max: 0.296
- M_min: 0.019
- M_max: 0.021
- N_min: 1.925
- N_max: 1.955
- P_min: None
- P_max: 2.438
- R_min: 0.125
- R_max: 0.155
- S_min: 0.245
- S_max: 0.275
- Current_rating_min: 0.2
- Current_rating_max: 0.5
- Voltage_frequency_time_delay_code: See tables III, IV, V and VIII
- Interrupting_capacities_240V: 1000 amperes
- Interrupting_capacities_120V: 2000 amperes
- Actuator_strength: 25 pounds
- Actuator_operating_force: 8 pounds
