ALPHA WIRE 1299CSL002 Shielded Electronic Cable
The 1299C SL002 is a 9-core shielded cable with a tinned copper conductor and PVC insulation. Featuring a slate-colored PVC jacket and an aluminum/Mylar foil shield with outward-facing foil, it offers excellent EMI protection. Designed for versatile electronic uses, it supports a maximum pull tension of 55 pounds, has a ground capacitance of 90 pF/ft at 1 kHz, an inductance of 0.18 µH/ft, and a DC resistance of 16.4 Ω/1000 ft. Suitable for audio, communication, sensors, automation, and consumer electronics, ensuring reliable signal integrity in demanding environments.
ALPHA WIRE 1299CSL002 Shielded Electronic Cable Specifications:
- Conductor: Tinned copper, 22 AWG TC
- Insulation: PVC, 0.010" wall
- Jacket: PVC, 0.032" wall, slate-colored
- Shield: Aluminum/Mylar tape, 25% overlap, foil facing out
- Max pull tension: 55 Lbs
- Voltage rating: 300 V
- Capacitance: 50 pF/ft @1 kHz
- Ground capacitance: 90 pF/ft @1 kHz
- Inductance: 0.18 µH/ft
- DC Resistance: 16.4 Ω/1000 ft
- Shield Resistance: 11.8 Ω/1000 ft @20°C
- Temperature Range: -20°C to 80°C
- Bend Radius: 10X cable diameter
- Length options: 1000 ft, 500 ft, 100 ft
- Compliance: UL AWM 2576, CSA Type CM, FT4, RoHS
Buy the Buy Alpha Wire Part Number 1299C Online
Purchase the Alpha Wire 1299C shielded cable online today for versatile electronic applications such as automation, audio, and sensors. Featuring 9 cores with tinned copper conductors, PVC insulation, and aluminum/Mylar shielding for excellent EMI protection, this cable supports a maximum pull tension of 55 pounds. It has a ground capacitance of 90 pF/ft, an inductance of 0.18 µH/ft, and a DC resistance of 16.4 Ω/1000 ft. Its flexible design and high-quality materials make it perfect for demanding electronic environments, ensuring reliable performance and easy installation.
Order your Alpha Wire Series1299C shielded cable today and ensure reliable signal quality for your electronic and automation projects.
Frequently Asked Questions
Where can I buy ALPHA WIRE 1299CSL002?
You can click on the BUY or RFQ button to purchase 1299CSL002 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 1299CSL002?
You can download the 1299CSL002 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 1299CSL002?
ALPHA WIRE
