ALPHA WIRE 172619WHITE100 Hook Up Wire
The ALPHA WIRE 172619-WHITE-100 is a versatile hook-up wire suitable for a wide range of applications, including internal wiring of appliances, electronics, and machinery. Constructed with 19/38 stranded annealed tinned copper conductors and a durable PVC insulation, this wire provides reliable performance and electrical insulation. It meets UL VW-1 flammability standards and is RoHS compliant, ensuring environmental responsibility. The wire's flexibility and robust construction make it ideal for use in challenging environments, while its compact design allows for easy routing in tight spaces.
ALPHA WIRE 172619WHITE100 Hook Up Wire Specifications:
- Component 1: 1 X 1 HOOKUP
- Conductor AWG: 26 (19/38) AWG TC
- Insulation Wall: 0.010" Nom. PVC
- Insulation Diameter: 0.040+/- 0.002"
- Colors: WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN, ORANGE, SLATE, VIOLET
- UL Rating: VW-1
- Military Spec: MIL-W-16878E/1
- Temperature Range: -55 to 105°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 2.39 Lbs, Maximum
- Voltage Rating: 600 VRMS
- Inductance: 0.06 µH/ft, Nominal
- Conductor DCR: 37 Ω/1000ft @20°C, Nominal
- Packaging 5000 FT: 6.5 x 6 x 1.9 inches
- Packaging 1000 FT: 6.5 x 2 x 1.9 inches
- Packaging 500 FT: 3.5 x 3 x 1.125 inches
- Packaging 100 FT: 2.75 x 1 x 1.125 inches
- SVHC Compliant: Yes
- RoHS Compliant: Yes
Buy the 172619-WHITE-100 ALPHA WIRE Hook Up Wire | myMectronic
Purchase the ALPHA WIRE 172619-WHITE-100 hook-up wire securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy ALPHA WIRE 172619WHITE100?
You can click on the BUY or RFQ button to purchase 172619WHITE100 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 172619WHITE100?
You can download the 172619WHITE100 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 172619WHITE100?
ALPHA WIRE
