Alpha Wire 1805WH005 Electrical Wire
A 100-foot spool of 30 AWG single conductor wire made with solid ETFE insulation, featuring a white color finish. Suitable for electronic and electrical applications requiring durable and high-performance wiring.
Alpha Wire 1805WH005 Electrical Wire Specifications:
- Conductor Gauge: 30 AWG, solid
- Insulation Material: ETFE (Fluoropolymer)
- Insulation Thickness: 0.0045 inches, Wall
- Insulation Diameter: 0.020 +/- 0.002 inches
- Color: White
- Temperature Range: -70°C to 150°C
- Bend Radius: 10X Cable Diameter
- Maximum Pull Tension: 0.79 Lbs
- Inductance: 0.06 Nominal
- Conductor Resistance (DCR): 104 /1000ft @20°C, Nominal
- Cable Dimensions: 2.75 x 2 x 1.125 inches for 1000 ft spool
- Outer Length: 100 ft per spool
- Applicable Standards: UL 1516 (105°C), RoHS compliant
- Environmental Compliance: Meets EU Directive 2002/95/EC, California Proposition 65
- Operational Temperature: -70°C to 150°C
Buy the Alpha Wire Series 711 30 AWG: 1805WH005
Purchase Alpha Wire 1805WH005 online today—designed with solid ETFE insulation, this 30 AWG single conductor wire ensures durability, temperature resistance from -70°C to 150°C, and high electrical performance. Perfect for electronic and electrical applications requiring reliable, high-quality wiring. Available in a convenient 100-foot spool, this wire meets UL standards and RoHS compliance, making it ideal for demanding industrial, commercial, or DIY projects where safety and longevity are paramount. Order now for fast delivery and dependable operation.
Get Alpha Wire 1805WH005 today—built for durability, high-performance, and reliable electrical connections in demanding environments.
Frequently Asked Questions
Where can I buy Alpha Wire 1805WH005?
You can click on the BUY or RFQ button to purchase 1805WH005 from an authorized Alpha Wire distributor.
How do I troubleshoot issues or seek technical support for part 1805WH005?
You can download the 1805WH005 datasheet or visit the Alpha Wire website for support.
Who is the manufacturer of 1805WH005?
Alpha Wire
