Alpha Wire 2461CSL001 Shielded Electronic Cable
This shielded cable assembly features dual 22 AWG TC conductors with a 0.008-inch wall polyprop insulation, and a PVC jacket with a 0.020-inch wall. Designed for electronic applications, it includes a foil shield with alum/mylar tape and a drain wire for noise reduction. The cable is rated for 300 V, operates in temperatures from -20°C to 75°C, and has a bend radius of 10 times the cable diameter. It meets UL, CSA Type CMG specifications and complies with European RoHS and REACH regulations, ensuring environmental safety and durability.
Alpha Wire 2461CSL001 Shielded Electronic Cable Specifications:
- Conductor: 22 AWG TC
- Insulation: 0.008" Wall, Polypropylene
- Jacket: 0.020" Wall, PVC, Black
- Shield: Alum/Mylar Tape, 25% Overlap
- Drain Wire: 22 AWG TC
- Twists: 9.6 Twists per foot (minimum)
- Voltage Rating: 300 V
- Temperature Range: -20°C to 75°C
- Bend Radius: 10x Cable Diameter
- Pull Tension: 16.5 Lbs, Max
- Length Options: 1000 FT, 500 FT, 100 FT, 1000 FT in Reel
- Certifications: UL Listed, CSA Type CMG
- RoHS-Compliant, REACH compliant, California Proposition 65 compliant
Buy the Buy AlphaWire Cable Part Number 2461C Online
Discover the premium quality shielded electronic cable from AlphaWire, part number 2461C. Designed for reliable performance, it features dual 22 AWG TC conductors, foil shielding with alum/mylar tape, and a PVC jacket. Rated for 300 V and operating from -20°C to 75°C, this cable ensures minimal noise and maximum durability in electronic systems. Certified by UL and CSA, and compliant with RoHS, it guarantees safety and environmental compliance. Order online today and ensure your projects benefit from high-quality, compliant wiring solutions.
Order your AlphaWire Part Number 2461C today and equip your electronic projects with a durable, shielded cable rated for 300 V and compliant with environmental standards.
Frequently Asked Questions
Where can I buy Alpha Wire 2461CSL001?
You can click on the BUY or RFQ button to purchase 2461CSL001 from an authorized Alpha Wire distributor.
How do I troubleshoot issues or seek technical support for part 2461CSL001?
You can download the 2461CSL001 datasheet or visit the Alpha Wire website for support.
Who is the manufacturer of 2461CSL001?
Alpha Wire
