ALPHA WIRE 2636YL001 Industrial Wiring Cable
This professional-grade wiring cable features a 36 AWG solid copper conductor with a 0.006-inch wall PFA insulation available in multiple colors including white, black, red, green, yellow, blue, brown, and orange. Designed for high-temperature environments, it operates from -150°C to 300°C and has a voltage rating of 600 V. Its flexible, water and chemical-resistant construction makes it suitable for a variety of industrial and electronic applications requiring durability and reliability under harsh conditions, ensuring optimal performance across diverse environments.
ALPHA WIRE 2636YL001 Industrial Wiring Cable Specifications:
- Conductor: 36 AWG solid copper, 0.005 inch diameter, 10% nickel plated
- Insulation: 0.006 inch wall, PFA material, color options include white, black, red, green, yellow, blue, brown, and orange
- Temperature Range: -150°C to 300°C
- Voltage Rating: 600 V
- Inductance: 0.09 LH/ft, Nominal
- Conductor Resistance: 471 Ohm/1000 ft at 20°C
- Bend Radius: 10 times cable diameter
- Maximum Pull Tension: 0.2 lbs
- Cable Dimensions: 2.75 in x 2 in x 1.125 in (continuous length)
- Water & Chemical Resistance: Yes
- RoHS & REACH Compliant: Yes
- Applicable Standards: European RoHS 2011/65/EU, RoHS 2015/863/EU, REACH Regulation EC 1907/2006
- Certifications: Complies with EU Low Voltage Directive 2014/35/EU
Buy the Alpha Wire 2636YL001 – Reliable Industrial Wiring Cable for Electronic Applications
Order the Alpha Wire Industrial Wiring Cable today to ensure reliable connections in demanding environments. With a 36 AWG copper conductor, PFA insulation, and exceptional temperature range from -150°C to 300°C, this cable is ideal for industrial, electronic, and harsh environment applications. Its water and chemical resistance, combined with compliance to major safety standards, provides durability, safety, and flexibility. Purchasing online guarantees quick delivery, competitive pricing, and top-quality specifications essential for industrial projects or electronic systems needing dependable wiring components.
Buy Alpha Wire 2636YL001 now and experience unmatched reliability and performance with high-temperature resistance and water-resistant features.
Frequently Asked Questions
Where can I buy ALPHA WIRE 2636YL001?
You can click on the BUY or RFQ button to purchase 2636YL001 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 2636YL001?
You can download the 2636YL001 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 2636YL001?
ALPHA WIRE
