ALPHA WIRE 3469CSLATE100 Multi-Conductor Cable Assembly
The ALPHA WIRE 3469C-SLATE-100 is a multi-conductor cable assembly designed for reliable signal and power transmission in diverse industrial environments. It consists of three 20 AWG stranded conductors, each insulated with PVC and color-coded for easy identification. The cable is shielded with a slate-colored PVC jacket, providing durability and protection against external interference. This cable is RoHS compliant and meets UL and CSA safety standards, making it suitable for applications requiring high performance and regulatory compliance. It is commonly used in automation, control systems, and data transmission applications.
ALPHA WIRE 3469CSLATE100 Multi-Conductor Cable Assembly Specifications:
- Conductor AWG: 20 (7/28) AWG TC
- Insulation Wall Thickness: 0.016" Nom. PVC
- Color Code: Alpha Wire Color Code D (Black, Red, White)
- Cable Twists: 5.3 Twists/foot (min)
- Jacket Wall Thickness: 0.020" Nom. PVC
- Jacket Color: Slate, Black
- Print: ALPHA WIRE-* P/N 1896C 3C 20 AWG (UL) 75C TYPE CM OR AWM 2509 --- LLXXXXXX CSA TYPE CMG FT4 CE ROHS * = Factory Code
- UL Style: AWM/STYLE 2509
- UL Voltage Rating: 80°C / 300 VRMS
- UL Temperature Rating: 75°C
- UL Flammability Rating: VW-1
- CSA Rating: CMG 60°C
- CSA Flammability Rating: FT4
- CE Compliance: EU Low Voltage Directive 2006/95/EC
- RoHS Compliance: Complies with EU Directive 2011/65/EU
- REACH Compliance: Does not contain SVHCs above 0.1% mass
- Temperature Range: -20 to 80°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 26 Lbs, Maximum
- Voltage Rating: 300 VRMS
- Capacitance: 30 pf/ft @1 kHz, Nominal Conductor to Conductor
- Inductance: 0.19 µH/ft, Nominal
- Conductor DCR: 10.2 Ω/1000ft @20°C, Nominal
- 1000 FT Dimensions: 12 x 10 x 5 inches
- 500 FT Dimensions: 12 x 4.5 x 3.5 inches
- 100 FT Dimensions: 6.5 x 4 x 2.5 inches
